ACI SST5630AE

Name: ACI SST5630AE
Brand: ACI
SKU: CS6287497
Availability: OutOfStock

SKU: CS6287497MPN: SST5630AEAlternate Part #: 134785

Wireless, Wireless Low Temp, Strap on/Remote, NEMA 4X Enclosure

Product Details

Wireless, Wireless Low Temp, Strap on/Remote, NEMA 4X Enclosure

Accuracy	+/- 1ºF (+/- 0.555ºC) 12 bit resolution
Battery Life	2-3 years typical
Probe Length	Length: 2.0” (50.80 mm) \| Diameter: 0.188” (4.78 mm) \| Material: 304 stainless steel
Data Protocol	IEEE 802.15.4-2003/2006
Input Voltage	Battery; 1 (Duracell DL123A), Lithium 3V 1400 mAh 45 mA maximum
Product Weight	0.85 lbs (0.39 kg)
Fitting Material	Nylon 6/6, Flammability rating UL94V-2
Data Transmission	75 seconds (default) \| 300 seconds (optional)
Product Dimensions	(L) 4.52” (114.81 mm) x (W) 2.55“ (64.77 mm) x (H) 2.16” (54.86 mm)
RF Characteristics	900 MHz, Operating Frequency 10 channels between 902 – 928 MHz Transmitter Power: 11 dBm \| Receiver Sensitivity: -11 dBm
Transmission Distance	200 – 300 ft horizontally depending on building type and construction, and typically one floor above and below the transceiver vertically
Connections \| Wire Size	24 AWG (0.51 mm) \| Silver Plated Copper
Operating Humidity Range	5 to 65%, Non-condensing
Storage Temperature Range	0 to 140ºF (-17.70 to 60ºC), 5 to 65% RH, Non-condensing
Operating Temperature Range	14 to 140ºF (-10 to 60ºC)
Lead Length \| Conductor Size	10’ (9.15 m) \| 0.106” nominal (2.69 mm)
Lead Wire Insulation \| Wire Rating	FEP/FEP (Tefon) Jacketed Cable \| White
Sensor Operating Temperature Range	-300 to 300ºF (-184 to 149ºC)
Enclosure Material \| Flammability Rating	Polycarbonate Plastic \| UL94-HB
