Siemens SKB82.51U
SKU: CS608743MPN: SKB82.51UUPC/EAN: 4047625020149
Flowrite Electro-Hydraulic Actuator, Float Control, Spring Rtn, ¾-in Stroke
$1,527.63
UnitAvailable on backorder
Product Details
The Flowrite SKB Valve Actuator is used with Flowrite and other standard valves with a ¾-inch stroke. This electronic valve actuator requires a 24 Vac supply to provide floating control of the valve. Other features of this valve actuator include automatic stroke calibration, manual override, die-cast aluminum housing, 1000 lb (4000N) thrust, and spring return functionality.
Attributes
| Ambient Temperature Operation | -15…55 °C |
| Fail Safe | Yes |
| Frequency | 50/60 |
| Medium Temperature | -25…220 °C; 5…130 ºF |
| Medium Temperature F Max | 130 ºF |
| Medium Temperature F Min | 5 ºF |
| Operating Voltage | 19.2…28.2 V24 V#AC |
| Positioning Time | 120 s |
| Power Consumption | 12 VA |
| Spring Return Function | Spring return functionality |
| Stroke | 20 mm |
| Supply Voltage | 24 VAC |
Specifications
| SKU | CS608743 |
|---|---|
| MPN | SKB82.51U |
| UPC/EAN | 4047625020149 |
