ACI FT2630A-02

Name: ACI FT2630A-02
Brand: ACI
SKU: CS6287076
Availability: OutOfStock

SKU: CS6287076MPN: FT2630A-02Alternate Part #: 131033

Wireless, Temp, Immersion, 2.5”, No Well

Product Details

Wireless, Temp, Immersion, 2.5”, No Well

Product Configuration

Enclosure	Standard

Product Family Specifications

Accuracy	+/- 1ºF (+/- 0.555ºC) 12 bit resolution
Battery Life	2-3 years typical
Probe Length	2.5”, 4”, \& 6“
Data Protocol	IEEE 802.15.4-2003/2006
Input Voltage	Battery; 1 (Duracell DL123A), Lithium 3V 1400 mAh 45 mA maximum
Sensing Range	-40 to 200ºF (-40 to 93ºC)
Probe Diameter	0.250” (6.35mm)
Probe Material	304 Stainless Steel
Product Weight	FT2630A-02: 0.98 lbs (0.45 kg) FT2630A-04-SS: 1.29 lbs (0.59 kg) FT2630AE-06: 2.83 lbs (1.28 kg) FT2630A-04: 0.99 lbs (0.45 kg) FT2630A-06-SS: 1.30 lbs (0.59 kg) FT2630AE-02-SS: 3.11 lbs (1.41 kg) FT2630A-06: 1.00 lbs (0.45 kg) FT2630AE-02: 2.81 lbs (1.27 kg) FT2630AE-04-SS: 3.17 lbs (1.44 kg) FT2630A-02-SS: 1.28 lbs (0.58 kg) FT2630AE-04: 2.82 lbs (1.28 kg) FT2630AE-06-SS: 3.23 lbs (1.47 kg)
Data Transmission	75 seconds (default) \| 300 seconds (optional)
Enclosure Material	Standard: UL94 NEMA 4X: UL94-HB
Product Dimensions	Standard: (L) 5.77” (146.56 mm) x (W) 3.19” (81.03 mm) x (H) 1.88” (47.75 mm) NEMA 4X: (L) 4.52” (114.81 mm) x (W) 3.54” (89.92 mm) x (H) 2.16” (54.86 mm)
RF Characteristics	900 MHz, Operating Frequency 10 channels between 902 – 928 MHz Transmitter Power: 11 dBm \| Receiver Sensitivity: -11dBm
Transmission Distance	200 – 300 ft horizontally depending on building type and construction, and typically one floor above and below the transceiver vertically
Operating Humidity Range	5 to 65%, Non-condensing
Operating Temperature Range	14 to 140ºF (-10 to 60ºC)
Storage Temperature \| RH Range	Temperature: 0 to 176ºF (-17 to 80ºC) \| Humidity: 5 to 65%, Non-condensing
Fitting Material \| Flammability Rating	ST801A Polyamide 66 Plastic (PA66) toughened “Zytel”, UL94-HB
Thermowell Instrument Thread \| Process Thread	304 Stainless Steel, ½” NPT Process Threads, ½” NPS Instrument Threads
