Carrier ZP29K5E-TFE-830
SKU: CS5791154MPN: ZP29K5E-TFE-830
COMPRESSOR
Contact us for pricing and availability
Product Details
COMPRESSOR
Attributes
| Amps | 4.2 |
| Phase | Three |
| Voltage | 575 VAC |
| Oil Type | Polyolester (POE) |
| UL Listed | Yes |
| BTU Output | 29,000 |
| Protection | Internal Inherent Protection |
| Cycle/Hertz | 60 Hz |
| Refrigerant | R-410A; R-410B |
| Displacement | 1.68 (in^3/Rev) |
| Compressor Type | Scroll |
| Sound Level (dBA) | 69 |
| Compressor Housing | Hermetic |
| Liquid Temperature | 85°F to 115°F (29.44°C to 46.11°C) |
| Mass Flow (lbs/hr) | 427 lbs./hr.; 486 lbs./hr. |
| Mounting Dimensions | 7.5” x 7.5” x 16.02” |
| Rated Load Amps (RLA) | 4.2 |
| Substantial Commodity | Steel |
| Condensing Temperature | 100°F to 130°F (37.78°C to 54.44°C) |
| Return Gas Temperature | 65°F |
| Suction Line Size (OD) | ¾” |
| Evaporating Temperature | 45°F |
| Locked Rotor Amps (LRA) | 36.5 |
| Oil Charge Initial (oz.) | 21 |
| Discharge Connection Type | Stub |
| Suction Line Fitting Type | Stub |
| Discharge Connection Size (OD) | ½” |
Specifications
| SKU | CS5791154 |
|---|---|
| MPN | ZP29K5E-TFE-830 |
