Carrier ZP31K6E TFE 830

Name: Carrier ZP31K6E TFE 830
Brand: Carrier
SKU: CS4231038
Availability: OutOfStock

SKU: CS4231038MPN: ZP31K6E TFE 830Alternate Part #: CAR-ZP31K6E-TFE-830

Factory Authorized Parts™ - ZP31K6E-TFE-830 - Compressor Scroll

Carrier ZP21K5E PFJ 830, ZP31K6E PFV 830, ZP31K6E TFD 830, ZP31K6E TFE 830

Product Details

Factory Authorized Parts™ - ZP31K6E-TFE-830 - Compressor Scroll

Please note, this is a special order, non-stock item and will be shipped direct from the vendor. Non-stock and Special Order items cannot be cancelled once processed, and are non-returnable. Customer is responsible for freight charges. These items may have an extended lead time, up to 4-6 weeks. By purchasing this product, you agree to these terms.

Attributes

Amps	2.7
Phase	Three
Voltage	575 VAC
Oil Type	Polyolester (POE)
UL Listed	Yes
BTU Output	31,000
Protection	Internal Inherent Protection
Cycle/Hertz	60 Hz
Refrigerant	R-410A
Displacement	1.80 (in^3/Rev)
Compressor Type	Scroll
Sound Level (dBA)	71
Compressor Housing	Hermetic
Liquid Temperature	85°F to 115°F (29.44°C to 46.11°C)
Mass Flow (lbs/hr)	3.65 lbs./hr.
Mounting Dimensions	7.5” x 7.5” x 16.02”
Rated Load Amps (RLA)	3.8
Substantial Commodity	Steel
Condensing Temperature	100°F to 130°F (37.78°C to 54.44°C)
Return Gas Temperature	65°F to 70°F (18.33°C to 21.11°C)
Suction Line Size (OD)	¾”
Evaporating Temperature	45°F to 50°F (7.22°C to 10°C)
Locked Rotor Amps (LRA)	36.5
Oil Charge Initial (oz.)	25
Discharge Connection Type	Stub
Suction Line Fitting Type	Stub
Discharge Connection Size (OD)	½”
