Square D XS4P08NA340

Name: Square D XS4P08NA340
Brand: Square D
SKU: CS4814105
Availability: OutOfStock

SKU: CS4814105MPN: XS4P08NA340

Inductive proximity sensors XS, inductive sensor XS4 M8, L33mm, PPS, Sn2.5 mm, 12...24 VDC, cable 2 m

Product Details

Inductive sensor XS4 M8 - L33mm

Ambient Air Temperature For Operation	-25-70 °C
Ambient Air Temperature For Operation 1	-25-70 °C
Ambient Air Temperature For Storage	-40-85 °C
Body Type	fixed
Cable Composition	3 x 0.11 mm²
Detection Face	frontal
Detector Flush Mounting Acceptance	non flush mountable
Differential Travel	1…15% of Sr
Discrete Output Function	1 NO
Discrete Output Type	NPN
Enclosure Material	PPS
Front Material	PPS
Marking	CE
Marking 1	CE
Material	plastic
Maximum Delay First Up	10 ms
Maximum Delay Recovery	0.1 ms
Maximum Delay Response	0.1 ms
Operating Zone	0-2 mm
Output Circuit Type	DC
Product Certifications	Ecolab# #UL# #CSA
Range Of Product	Telemecanique Inductive proximity sensors XS
Sensor Design	cylindrical M8
Sensor Name	XS4
Sensor Type	inductive proximity sensor
Series Name	general purpose
Size	33 mm
Thread Type	M8 x 1
Type Of Output Signal	discrete
Wire Insulation Material	PvR
Wiring Technique	3-wire
