Square D XMLP1K0PD23

Name: Square D XMLP1K0PD23
Brand: Square D
SKU: CS4814074
Availability: OutOfStock

SKU: CS4814074MPN: XMLP1K0PD23

pressure transmitter - XMLP - 1000psi - ¼”18NPT - 4..20mA - M12 - set 1

Product Details

OsiSense XM Pressure Transmitter

Presure Sensor Size: 1000psi* Fluid Connection Type: ¼ in. - 18 NPT (male)* Electrical Connection: 1 male connector M12 4 pins* Rated Supply Voltage: 12-24V DC SELV, voltage limits: 8-30V* Type of Output Signal: Analog* Pressure Setting Range: 0-1000 psi* Operating Position: Any* Degree of Protection: IP69K, IP65, IP67 conforming to EN/IEC 60529

Uimp Rated Impulse Withstand Voltage	0.5 kV
Accuracy	infinity
Ambient Air Temperature For Operation	-30-100 °C
Ambient Air Temperature For Operation 1	-30-100 °C
Ambient Air Temperature For Storage	-30-100 °C
Current Consumption	< 20 mA
Destruction Pressure	6000 psi
Diameter	30 mm
Drift Of The Sensitivity	± 0.02 % of measuring range/°K
Drift Of The Zero Point	± 0.02 % of measuring range/°K
Electrical Circuit Type	control circuit
Local Display	without
Materials In Contact With Fluid	stainless steel type 17-4PH# #stainless steel type AISI 304
Maximum Permissible Accidental Pressure	2000 psi
Measurement Accuracy	± 0.5 % of the measuring range
Mechanical Durability	10000000 cycles
Operating Position	any position
Pressure Sensor Name	XMLP
Pressure Sensor Type	pressure transmitter
Pressure Setting Range	0-1000 psi
Product Certifications	EAC# #RCM# #cULus
Product Or Component Type	electronic pressure sensors
Protection Type	reverse polarity# #load short-circuit
Protective Treatment	TC
Quantity Per Set	set of 1
Range Of Product	OsiSense XM
Repeat Accuracy	± 0.2 % of the measuring range
Repeat Accuracy 1	± 0.2 % of the measuring range
Scale Type	fixed differential
Standards	CE# #EN/IEC 61326-1
Type Of Output Signal	analogue
Type Of Packing	individual
