Square D XMLP250MD71F

Name: Square D XMLP250MD71F
Brand: Square D
SKU: CS4814078
Availability: OutOfStock

SKU: CS4814078MPN: XMLP250MD71F

Electronic pressure sensors, Pressure sensors XM, transmitter 250mbar, 0...10 V, G¼ A male, FPM, M12

Product Details

OsiSense XM Pressure Transmitter

Presure Sensor Size: 250 mbar* Fluid Connection Type: D ¼A (male) conforming to DIN 3852-E* Electrical Connection: 1 male connector M12 4 pins* Rated Supply Voltage: 24V DC SELV, voltage limits: 12-33V* Type of Output Signal: Analog* Pressure Setting Range: 0-0.25 bar* Operating Position: Any* Degree of Protection: IP69K, IP65, IP67 conforming to EN/IEC 60529

Uimp Rated Impulse Withstand Voltage	0.5 kV
Ambient Air Temperature For Operation	-30-85 °C
Ambient Air Temperature For Operation 1	-30-85 °C
Ambient Air Temperature For Storage	-50-100 °C
Current Consumption	< 7 mA
Destruction Pressure	5 bar
Diameter	26 mm
Drift Of The Sensitivity	± 0.02 % of measuring range/°K
Drift Of The Zero Point	± 0.05 % of measuring range/°K
Electrical Circuit Type	control circuit
Local Display	without
Materials In Contact With Fluid	stainless steel AISI 316L# #fluorocarbon FPM# #ceramic
Maximum Permissible Accidental Pressure	3 bar
Measurement Accuracy	± 2 % of the measuring range
Mechanical Durability	10000000 cycles
Operating Position	any position
Pressure Sensor Name	XMLP
Pressure Sensor Type	pressure transmitter
Pressure Setting Range	0-0.25 bar
Product Certifications	CE# #RCM# #cULus# #EAC
Product Or Component Type	electronic pressure sensors
Protection Type	reverse polarity# #load short-circuit
Quantity Per Set	set of 1
Range Of Product	OsiSense XM
Repeat Accuracy	± 0.2 % of the measuring range
Repeat Accuracy 1	± 0.2 % of the measuring range
Standards	EN/IEC 61326-2-3# #NSF ANSI 61
Type Of Output Signal	analogue
Type Of Packing	individual
