Square D XMLP030RD23F

Name: Square D XMLP030RD23F
Brand: Square D
SKU: CS4814069
Availability: OutOfStock

SKU: CS4814069MPN: XMLP030RD23F

Electronic pressure sensors, Pressure sensors XM, transmitter 30 PSI, 4...20 mA, ¼ 18NPT male, FPM, M12

Product Details

OsiSense XM Pressure Transmitter

Presure Sensor Size: 30psi* Fluid Connection Type: ¼ in. - 18 NPT (male)* Electrical Connection: 1 male connector M12 4 pins* Rated Supply Voltage: 12-24V DC SELV, voltage limits: 7-33V* Type of Output Signal: Analog* Pressure Setting Range: 0-30 psi* Operating Position: Any* Degree of Protection: IP69K, IP65, IP67 conforming to EN/IEC 60529

Uimp Rated Impulse Withstand Voltage	0.5 kV
Accuracy	0.1 % of the measuring range
Ambient Air Temperature For Operation	-30-85 °C
Ambient Air Temperature For Operation 1	-30-85 °C
Ambient Air Temperature For Storage	-50-100 °C
Current Consumption	< 23 mA
Destruction Pressure	145 psi
Diameter	26 mm
Drift Of The Sensitivity	± 0.02 % of measuring range/°K
Drift Of The Zero Point	± 0.02 % of measuring range/°K
Electrical Circuit Type	control circuit
Local Display	without
Materials In Contact With Fluid	fluorocarbon FPM# #stainless steel AISI 316L# #ceramic
Maximum Permissible Accidental Pressure	109 psi
Measurement Accuracy	± 0.5 % of the measuring range
Mechanical Durability	10000000 cycles
Operating Position	any position
Pressure Sensor Name	XMLP
Pressure Sensor Type	pressure transmitter
Pressure Setting Range	0-30 psi
Product Certifications	RCM# #EAC# #CE# #cULus
Product Or Component Type	electronic pressure sensors
Protection Type	reverse polarity# #load short-circuit
Quantity Per Set	set of 1
Range Of Product	OsiSense XM
Repeat Accuracy	± 0.25 % of the measuring range
Repeat Accuracy 1	± 0.25 % of the measuring range
Standards	EN/IEC 61326-2-3# #NSF ANSI 61
Type Of Output Signal	analogue
Type Of Packing	individual
