Dwyer PLS2-E-1-2

Name: Dwyer PLS2-E-1-2
Brand: Dwyer
SKU: CS4119925
Price: 385.53 USD
Availability: OutOfStock

SKU: CS4119925MPN: PLS2-E-1-2Alternate Part #: 124854-02

PLS2-E-1-2 PDL LVL SW 230 VAC

$385.53

Unit

Available on backorder

Quantity

remove

add

Product Details

Explosion-proof paddle level switch, 230 VAC power supply

Commodity Code	R6LA
Compliance	CE, FM.
Conduit Connection	¾” female NPT.
Electric Connections	Screw terminals.
Electrical Rating	5 A @ 250 VAC, 3 A @ 30 VDC.
Enclosure	Aluminum, powder coated.
Enclosure Rating	NEMA 4 (IP66); Rated for Class II & III, Div. 1, Group E, F, G.
Mounting Orientation	Side or top mounting.
Permitted Mechanical Loading	Standard shaft: 67 lbf (300 N) max; Optional extension: 22 lbf (100 N) max.
Power Consumption	AC versions: 4 VA; DC version: 2.5 watt.
Power Requirement	Select by model number: 115 VAC, 230 VAC or 24 VDC.
Pressure Limit	11.6 psi (0.8 bar).
Process Connection	1-¼” male NPT.
Sensitivity	Minimum material density of 6 lb/ft3 (96 kg/m3).
Service	Dry powder or bulk materials compatible with wetted materials.
Switch Type	SPDT micro switch.
Wetted Material	Paddle: 304 SS; Exposed shaft: 303 SS; Shaft seal: NBR; Process connection: Aluminum.
