Dwyer PLS-W-S-1-2-CSH-0-0

SKU: CS4119922MPN: PLS-W-S-1-2-CSH-0-0Alternate Part #: 126300-02

PLS-W-S-1-2-CSH-0-0 PAD LVL SW

$627.31
Unit
Available on backorder
remove
add

Product Details

Paddle level switch, SPDT, weatherproof, 120 VAC power supply, includes PDL-1 paddle and FLG-CSH flange.

Attributes

Commodity Code 8512
Compliance cUL, UL approved as an auxiliary device or as an auxiliary device for hazardous locations.
Conduit Connection ¾” female NPT.
Electric Connections Screw terminals.
Electrical Rating 15 A @ 120.
Enclosure Aluminum, powder coated.
Enclosure Rating Weatherproof (W, WH construction): NEMA 4X, Explosion-proof (E, EH construction): NEMA 4X and rated for Class I, Div. 1 & 2, Groups C & D, Div. 1 & 2, Groups E, F, & G.
Indication Light Red LED that activates when switch is made or when switch is not made with RL option (not available on Explosion-proof models).
Power Consumption Weatherproof models: 5 watts, Explosion-proof models: 3 watts.
Power Requirement Select by part number: 110-120 VAC, 230 VAC, 24 VAC, 48 VAC, or 12 VDC.
Pressure Limit 30 psig (2.07 bar) maximum for .5 micron or larger material.
Process Connection 1-¼” male NPT. Optional flange.
Sensitivity Minimum material density of 5 lb/ft³ (80 kg/m³), maximum of 200 lb/ft³ (3200 kg/m³).
Service Dry powder or bulk materials compatible with wetted materials.
Switch Type SPDT or optional DPDT snap switch.
Time Delay Relay Option Five field adjustable ranges from 0-1 to 0-31 minutes. (RL option not available, DPDT option not available with 230 VAC time delay).
Wetted Material Paddles: 316 SS. Exposed Shaft: 316 SS. Shaft Seal: PTFE. Mounting Boss: Aluminum. Flexible Coupling: 316 SS. Mounting Flanges: Carbon Steel or 316 SS. Shaft Extension and Shaft Guards: Galvanized Steel or 316 SS.

Specifications

SKUCS4119922
MPNPLS-W-S-1-2-CSH-0-0
Alternate Part #126300-02
