Dwyer FS-2-W8
SKU: CS4118072MPN: FS-2-W8Alternate Part #: 124398-02
FS-2-W8 PADDLE FL SW 8’ LEADS
$97.15
UnitAvailable on backorder
Product Details
Paddle flow switch, 1” male NPT connection with 8 ft leads
Attributes
| Commodity Code | R5AA |
| Compliance | CE. |
| Electrical Connection | Cable gland with attached wire leads or optional conduit connection. |
| Electrical Rating | 10 A res, 3 A ind @ 250 VAC. |
| Enclosure | Die-cast aluminum alloy. |
| Enclosure Rating | NEMA 4 (IP64). |
| Mounting Orientation | Switch must be installed vertically on horizontal pipe runs. |
| Pressure Limit | 145 psig (10 bar). |
| Process Connection | 1” male NPT or BSPT. |
| Service | Compatible liquids. |
| Set Point Adjustment | Four vane combinations and an adjustment screw. |
| Switch Type | SPDT snap switch. |
| Wetted Material | Bellow: Tin-bronze; Vane: SS; Body: Forged brass. |
Specifications
| SKU | CS4118072 |
|---|---|
| MPN | FS-2-W8 |
| Alternate Part # | 124398-02 |
