Square D K1D011B

Name: Square D K1D011B
Brand: Square D
SKU: CS3006490
Price: 128.75 USD
Availability: InStock

SKU: CS3006490MPN: K1D011BUPC/EAN: 3389110476804

Cam switch body for BCD encoded withoutput switch, Harmony K, Ø 22mm, plastic, 1 pole, 11 positions, 45°, 12A

$128.75

Unit

5+ Units Available at Factory - Ships Same/Next Business Day

Quantity

remove

add

Product Details

CAM SWITCH CONTACT BLOCK

Ithe Conventional Enclosed Thermal Current	0.417
Ambient Air Temperature For Operation	-25-55 °C
Ambient Air Temperature For Operation 1	-25-55 °C
Ambient Air Temperature For Storage	-40-70 °C
Bezel Material	plastic
Cam Switch Function	BCD encoded output switch
Component Name	K1
Contact Operation	slow-break
Fixing Mode	Ø 22 mm hole
Mechanical Durability	1000000 cycles
Mounting Location	front
Number Of Decimal	11.0
Off Position	with Off position
Positive Opening	with
Product Or Component Type	cam switch body
Protective Treatment	TC
Range Of Product	Harmony K
Short Circuit Current	10000 A
Sub Assembly Composition	contact blocks + fixing plate
Switching Angle	30 °
Switching Positions	right: 0°-30°-60°-90°-120°-150°-180°-210°-240°-270°-300°-330°
