Square D XS118BLPAM12

Name: Square D XS118BLPAM12
Brand: Square D
SKU: CS1681104
Availability: OutOfStock

SKU: CS1681104MPN: XS118BLPAM12UPC/EAN: 3389119002028

inductive sensor XS1 M18, L64mm, brass, Sn5mm, 12..24VDC, M12

Product Details

OsiSense XS Inductive Sensor

Sensor Design: Cylindrical M18* Enclosure Material: Nickel plated brass* Normal Sensing Distance: 5mm* 10-36V DC* Discrete Output Function: 1 NO* Degree of Protection: IP67 Conforming to IEC 60529

Ambient Air Temperature For Operation	-25-70 °C
Ambient Air Temperature For Operation 1	-25-70 °C
Ambient Air Temperature For Storage	-40-85 °C
Body Type	fixed
Detection Face	frontal
Detector Flush Mounting Acceptance	flush mountable
Differential Travel	1…15% of Sr
Discrete Output Function	1 NO
Discrete Output Type	PNP
Enclosure Material	nickel plated brass
Front Material	PBT
Iso Thread	M18 x 1
Marking	CE
Marking 1	CE
Material	metal
Maximum Delay First Up	15 ms
Maximum Delay Recovery	0.3 ms
Maximum Delay Response	0.1 ms
Operating Zone	0-4 mm
Output Circuit Type	DC
Product Certifications	UL# #CSA
Range Of Product	Telemecanique Inductive proximity sensors XS
Sensor Design	cylindrical M18
Sensor Name	XS1
Sensor Type	inductive proximity sensor
Series Name	general purpose
Size	64 mm
Type Of Output Signal	discrete
Wiring Technique	3-wire
