Veris H934
VFD Compatible Current Switch with Integral Command Relay, N.O., Solid-State 0.1 Amp @ 30VAC/DC, Status LED, Relay Power LED, Detects belt loss
Product Details
VFD Compatible Current Switch with Integral Command Relay, N.O., Solid-State 0.1 Amp @ 30VAC/DC, Status LED, Relay Power LED, Detects belt loss - The Hawkeye 934 microprocessor based current status switch with integral command relay provides a unique solution for monitoring status and starting/stopping motors controlled by variable frequency drives. To provide accurate status on loads controlled by Variable Frequency Drives (VFD), the H934 stores the sensed amperage values for normal operation at various frequency ranges in nonvolatile memory. This information allows it to distinguish between a reduced amp draw due to normal changes in the frequency and abnormal amperage drop due to belt loss or other mechanical failures.
Attributes
| Product or Component Type | sensor |
| Ambient Air Temperature for Operation | -15-60 °C |
| Product Certifications | UL; CE |
| Type of Measurement | AC current; variable frequency drive (VFD) |
| Device Application | building automation systems |
| Mounting Support | split core housing |
| Sensor Type | current switch, AC |
| Relative Humidity | 10-90 % RH, non-condensing |
| Relay Type | mechanical |
| Network Frequency | 50…60 Hz |
| Switch Function | SPST |
| AWG Gauge | AWG 24…AWG 14 |
| Relay Coil Voltage | 24-24 V AC; 24-24 V DC |
| Output Current | 0.1 A at 30 V AC/DC |
| Current Measurement Range | 3.5…135 A |
| Opening Width | 21 mm |
| Load Type | resistive: 5 Aat250 V AC; resistive: 5 Aat30 V DC |
Specifications
| SKU | CS696000 |
|---|---|
| MPN | H934 |
| Alternate Part # | VER-H934 |
