Veris H730

Current Switch w/Relay: Fixed Trip Point, 0.5 - 200 Amp Range, Normally Open 1.0A@30VAC/DC, 0.5A or less Minimum Trip Point, Solid-Core Housing, LED

Current Switch w/Relay:

• Fixed Trip Point* 0.5-200 Amperage Range* Normally Open 1.0A@30VAC/DC* 0.5A or less Minimum Trip Point* SPST, N.O. Relay* 24VAC/DC Relay Coil* Solid-Core Housing* LED Status Indicator* Relay Power LED* Sensor Power Induced from monitored conductor* Insulation Class 600VAC RMS* Frequency Range 50/60 HZ* Temperature Range -15 deg. to 60 deg. C (5 deg. to 140 deg. F)* Humidity Range 10-90% RH, non-condensing* Terminal Block Maximum Wire Size 14 AWG* Terminal Block Torque (nominal) 4 in-lbs (0.45 N-m)* Agency Approvals UL 508 open device listing
