Carrier ZR48K5E-TF5-830

Name: Carrier ZR48K5E-TF5-830
Brand: Carrier
SKU: CS5467050
Price: 3160.11 USD
Availability: OutOfStock

SKU: CS5467050MPN: ZR48K5E-TF5-830

Copeland Scroll Compressor, 48,000 BTUh

$3,160.11

Unit

Available on backorder

Quantity

remove

add

Product Details

ZR48K5E-TF5-830 is an official OEM Copeland Scroll Compressor, 48,000 BTUh for Carrier HVAC equipment

Amps	17.1
Phase	Three
Voltage	200-220/200-230 VAC
Oil Type	Polyolester (POE)
UL Listed	Yes
BTU Output	48,200
Protection	Internal Inherent Protection
Cycle/Hertz	50/60 Hz
Refrigerant	R-134a; R-22; R-407C
Displacement	3.87 in^3/Rev
Compressor Type	Scroll
Sound Level (dBA)	73
Compressor Housing	Hermetic
Liquid Temperature	85°F (29.44°C); 115°F (46.11°C)
Mass Flow (lbs/hr)	705 lbs./hr.; 800 lbs./hr.
Mounting Dimensions	7.5” x 7.5” x 17.17”
Rated Load Amps (RLA)	15.4
Substantial Commodity	Steel
Condensing Temperature	100°F to 130°F (37.78°C to 54.44°C)
Return Gas Temperature	70°F (21.11°C)
Suction Line Size (OD)	⅞”
Evaporating Temperature	50°F (10°C)
Locked Rotor Amps (LRA)	114
Oil Charge Initial (oz.)	42
Discharge Connection Type	Stub
Suction Line Fitting Type	Stub
Discharge Connection Size (OD)	½”
