Square D ATSU01N232LT

Name: Square D ATSU01N232LT
Brand: Square D
SKU: CS4810631
Price: 342.79 USD
Availability: OutOfStock

SKU: CS4810631MPN: ATSU01N232LT

soft starter for asynchronous motor, Altistart U01, TeSys U, ATSU01, 32A, 200 to 480V, 7.5 to 15kW

$342.79

Unit

Available on backorder

Quantity

remove

add

Product Details

Altistart 01 Soft Start (ATSU01)

For Asynchronous Motor* US Rated Supply Voltage: 200-480V* IcL Starter Rating: 32A* Motor Power Horsepower: 10 HP* Motor Power kW: 15 kW* Network Number of Phases: Triple-phase* Integrated Bypass* Assembly Style: with Heat Sink

Assembly Style	with heat sink
Deceleration Time Symb	adjustable from 1 to 10 s
Device Short Name	ATSU01
Discrete Input Voltage	24…40 V
Function Available	integrated bypass
Input Output Isolation	galvanic between power and control
Marking	CE
Network Frequency	47.5…63 Hz
Network Number Of Phases	3 phases
Operating Position	vertical ± 10 degree
Output Voltage	<= power supply voltage
Product Certifications	UL# #CCC# #CSA# #C-Tick
Product Destination	asynchronous motors
Product Or Component Type	soft starter
Product Specific Application	simple machine
Range Of Product	Altistart U01 and TeSys U
Standards	EN/IEC 60947-4-2
Starting Torque	30…80 % of starting torque of motor connected directly on the line supply
Supply Voltage Limits	180-528 V
Tightening Torque	1.9-2.5 N.m# #0.5-0.5 N.m
Tightening Torque 1	1.9-2.5 N.m# #0.5-0.5 N.m
Type Of Start	start with voltage ramp
