Schneider Electric MP2000-NSR

Name: Schneider Electric MP2000-NSR
Brand: Schneider Electric
SKU: CS4806738
Price: 1869.22 USD
Availability: OutOfStock

SKU: CS4806738MPN: MP2000-NSR

SmartX, Pressure Independent Valve Actuator, floating or proportional, non-spring return, 24 Vac/Vdc, 2000 N, 2 SPDT, IP54

$1,869.22

Unit

Available on backorder

Quantity

remove

add

Documents

Actuator: (MP2000-NSR):

Actuator Type: Electric
Control Signal: Proportional
Control Signal Range: 0 to 10 VDC, 0 to 20 mAdc
Loss of Power Type: Non-Spring Return
Power Input Voltage: 24 VAC
Leads and Connections: No leads
Force: 2000 N
Mechanical Movement: Linear
Additional Features: LED Status Indicator
Protection Rating: IP54
Product Line: Schneider Electric
Product Range: SmartX Actuator
Product Series: MP2000
Actuator Use: Dampers, Electronic Pressure Independent Characterized Control Valves

Product Alert: This product is not yet released

Us Rated Supply Voltage	24 V AC
Actuator	linear
Ambient Air Temperature For Operation	0-55 °C
Ambient Air Temperature For Storage	-40-70 °C
Analogue Input Range	0…10 V DC
Control Type	automatic reset
Electrical Insulation Class	class III
Ip Degree Of Protection	IP54
Power Consumption In Va	15 VA AC
Product Destination	pressure independent control valves
Product Or Component Type	actuator
Relative Humidity	5-95 % non-condensing
Stroke Running Time	6 s
Switch Function	2 SPDT
Targeted Region	North America.
Taxoclass Id	PTC_D54011_XXX
