Schneider Electric MP500C-SRD-W

Name: Schneider Electric MP500C-SRD-W
Brand: Schneider Electric
SKU: CS4806752
Price: 463.06 USD
Availability: OutOfStock

SKU: CS4806752MPN: MP500C-SRD-W

Spacelogic, Pressure Independent Valve Actuator, floating or proportional, spring return down, 24V AC/DC, 500N, IP65

$463.06

Unit

Available on backorder

Quantity

remove

add

Documents

Actuator: (MP500C-SRD-W):

Actuator Type: Electric
Control Signal: Proportional, Floating
Control Signal Range: 0 to 10 VDC, 4 to 20 mAdc
Loss of Power Type: Spring Return
Power Input Voltage: 24 VAC, 24 VDC
Leads and Connections: No leads
Force: 500 N
Mechanical Movement: Linear
Auxiliary Switch: Available as accessory
Additional Features: Field selectable floating input signal travel time
Protection Rating: IP65
Product Line: Schneider Electric
Product Range: Spacelogic Actuator
Product Series: MP500C-SR
Actuator Use: Dampers, Electronic Pressure Independent Characterized Control Valves

Product Alert: Spring return stem down

Us Rated Supply Voltage	24 V AC/DC
Actuator	linear
Ambient Air Temperature For Operation	-10-50 °C
Ambient Air Temperature For Storage	-25-65 °C
Analogue Input Range	0…10 V DC
Control Type	automatic reset
Force Lbf	113 lbf
Force N	500 N
Ip Degree Of Protection	IP65
Motor Type	brushless DC motor
Power Consumption In Va	30 VA AC
Product Destination	pressure independent control valves
Product Or Component Type	actuator
Relative Humidity	0-90 % RH, non-condensing
Stroke Running Time	30 s
Switch Function	2 SPDT
Targeted Region	Europe# #Asia Pacific.# #North America.# #Australia.
Taxoclass Id	PTC_D54011_XXX
Transformer Rated Power In Va	50 VA
