Schneider Electric MP500C

SKU: CS4806750MPN: MP500C

SpaceLogic MP500C Actuator for PIBCV Valves, Multi-Signal Control, Non-Spring Return, 24 Vac/Vdc, 500N.

Schneider Electric MP500C
$233.66
Unit
Available on backorder
remove
add

Product Details

Actuator: (MP500C):

  • Actuator Type: Electric
  • Control Signal: Proportional
  • Control Signal Range: 0 to 10 VDC, 4 to 20 mAdc
  • Loss of Power Type: Non-Spring Return, Stay in Place
  • Power Input Voltage: 24 Vac/dc
  • Leads and Connections: No leads
  • Force: 500 N
  • Mechanical Movement: Linear
  • Auxiliary Switch: Available as accessory
  • Additional Features: Field selectable floating input signal travel time
  • Protection Rating: IP54
  • Product Line: Schneider Electric
  • Product Range: SpaceLogic Actuator
  • Product Series: MP500C
  • Actuator Use: Pressure Independent Control Valves

Attributes

Us Rated Supply Voltage 24 V AC/DC
Actuator linear
Ambient Air Temperature For Operation -10-50 °C
Ambient Air Temperature For Storage -25-65 °C
Analogue Input Range 0…10 V DC
Control Type automatic reset
Electrical Insulation Class class III
Force Lbf 113 lbf
Force N 500 N
Ip Degree Of Protection IP54
Motor Type brushless DC motor
Power Consumption In Va 15 VA AC
Product Destination pressure independent control valves
Product Or Component Type actuator
Relative Humidity 0-90 % RH, non-condensing
Stroke Running Time 15 s
Switch Function 2 SPDT (optional)
Targeted Region Europe# #Asia Pacific.# #North America.# #Australia.
Taxoclass Id PTC_D54006_XXX
Transformer Rated Power In Va 50 VA

Specifications

SKUCS4806750
MPNMP500C
