APC SU2200R3X167

Name: APC SU2200R3X167
Brand: APC
SKU: CS4805402
Availability: OutOfStock

SKU: CS4805402MPN: SU2200R3X167UPC/EAN: 731304015475

APC Smart-UPS 2200VA RM 3U 120V/230V In 120V Out

Product Details

APC Smart-UPS 2200VA RM 3U 120V/230V In 120V Out

APC Global Deployment,1600 Watts /2200 VA,Input 120V, 230V /Output 120V, Interface Port DB-9 RS-232, SmartSlot, Rack Height 3 U

Includes: CD with software, Country-specific detachable power cord, Smart UPS signalling RS-232 cable, User Manual

Attributes

Sena Acoustic Level	47 dBA
Sena Additional Specification	TAA Compliant
Sena Alarm	alarm when on battery : distinctive low battery alarm : configurable delays
Sena Ambient Air Temperature For Operation	0-40 °C
Sena Ambient Air Temperature For Storage	-15-45 °C
Sena Battery Charger Power	223 W rated
Sena Battery Curve	Z
Sena Battery Life	3-5 year(s)
Sena Battery Recharge Time	3 h
Sena Battery Type	lead-acid battery
Sena Control Panel	LED status display with load and battery bar-graphs and on line : on battery : replace battery : and overload indicators
Sena Curve Equation	efficiency
Sena Curve Load Maximum	1.0000
Sena Curve X Axis Maximum	1.0000
Sena Curve X Axis Title	load
Sena Curve X Axis Units	percentage
Sena Curve Y Axis Maximum	1.0000
Sena Curve Y Axis Minimum	0.5000
Sena Curve Y Axis Title	efficiency
Sena Curve Y Axis Units	percentage
Sena Emergency Power Off	optional
Sena Free Slots	1.0000
Sena Graph Display	1.0000
Sena Harmonic Distortion	less than 5 % at full load
Sena Heat Dissipation	275 Btu/h
Sena Input Voltage	120 V 230 V
Sena Input Voltage 1	120 V 230 V
Sena Maximum Configurable Power In Va	2200 VA
Sena Maximum Configurable Power In W	1600 W
Sena Mounting Location	front
Sena Mounting Mode	rack-mounted
Sena Mounting Preference	lower
Sena Nb Of Power Socket Outlets	8 NEMA 5-15R
Sena Network Frequency	50/60 Hz ± 3 Hz auto-sensing
Sena Noise Suppression	full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Sena Number Of Battery Replacement Quantity	1.0000
Sena Number Of Cables	1.0000
Sena Number Of Rack Unit	3U
Sena Number Of Tare Power	45 W
Sena Operating Altitude	0…10000 ft
Sena Output Frequency	47…53 Hz for 50 Hz nominal sync to mains 57…63 Hz for 60 Hz nominal sync to mains
Sena Output Voltage	120 V
Sena Output Voltage 1	120 V
Sena Plug Standard	BS1363A British CEI 23-16 Italian NEMA 5-20P Schuko CEE 7 / EU1-16P
Sena Product Certifications	CSA# #TAA compliance
Sena Provided Equipment	CD with software country-specific detachable power cord Smart UPS signalling RS-232 cable user manual
Sena Provided Equipment 1	CD with software country-specific detachable power cord Smart UPS signalling RS-232 cable user manual
Sena Provided Equipment 2	CD with software country-specific detachable power cord Smart UPS signalling RS-232 cable user manual
Sena Rated Power In Va	2200 VA
Sena Rated Power In W	1600 W
Sena Redundant	No
Sena Relative Humidity	0-95 %
Sena Show Note Op Temperature	No
Sena Standards	FCC part 15 class A# #UL 1778
Sena Storage Altitude	0-50000 ft
Sena Storage Relative Humidity	0-95 %
Sena Surge Energy Rate	480 J
Sena Transfer Time	2 ms typical
Sena Ups Design Life	6 year(s)
Sena Ups Size	WS
Sena Ups Type	line interactive
Sena Usb Compatible	No
Sena Variant Option	special outlets
Sena Wave Type	sine wave
