APC SRT2200RMXLA

Name: APC SRT2200RMXLA
Brand: APC
SKU: CS3267412
Availability: OutOfStock

SKU: CS3267412MPN: SRT2200RMXLAAlternate Part #: APC-SRT2200RMXLAUPC/EAN: 731304323051

APC Smart-UPS On-Line, 2200VA, Rackmount 2U, 120V, 6x 5-20R+1x L5-20R NEMA outlets, SmartSlot, Extended runtime, W/ rail kit

APC SRT1000RMXLA, SRT3000RMXLA, SRT3000RMXLT

Documents

APC SRT1000RMXLA, SRT1500XLA, SRT192RMBP2, SRT3000RMXLA, SRT96BP Manual

Product Details

APC Smart-UPS SRT 2200VA RM 120V

Attributes

Sena Acoustic Level	55 dBA
Sena Additional Specification	high density
Sena Alarm	audible and visible alarms prioritized by severity
Sena Ambient Air Temperature For Operation	0-40 °C
Sena Ambient Air Temperature For Storage	-20-50 °C
Sena Battery Charger Power	102 W rated
Sena Battery Curve	D
Sena Battery Life	3-5 year(s)
Sena Battery Option	SRT72RMBP 1 916 VAh SRT72RMBP 10 6426 VAh SRT72RMBP 2 1530 VAh SRT72RMBP 3 2142 VAh SRT72RMBP 4 2754 VAh SRT72RMBP 5 3366 VAh SRT72RMBP 6 3978 VAh SRT72RMBP 8 5202 VAh
Sena Battery Recharge Time	3 h
Sena Battery Type	lead-acid battery
Sena Battery Voltage	72 V
Sena Bypass Type	built-in bypass
Sena Control Panel	multifunction LCD status and control console
Sena Crest Factor	0.126
Sena Curve Equation	efficiency
Sena Curve Fixed Loss	0.024900000542402
Sena Curve Load Maximum	1.0000
Sena Curve Load Minimum	0.029999999329448
Sena Curve Proportional Loss	0.017500000074506
Sena Curve Square Loss	0.041299998760223
Sena Curve Test Cond Id	Curve fit of data measured in accordance with the ENERGY STAR Test Method for Uninterruptible Power Supplies. All measurements taken in normal mode(s), at typical environmental conditions, with 120V/60Hz electrical input and balanced resistive load (PF =
Sena Curve X Axis Maximum	1.0000
Sena Curve X Axis Title	load
Sena Curve X Axis Units	percentage
Sena Curve Y Axis Maximum	1.0000
Sena Curve Y Axis Minimum	0.5000
Sena Curve Y Axis Title	efficiency
Sena Curve Y Axis Units	percentage
Sena Emergency Power Off	yes
Sena Extended Runtime	1.0000
Sena Free Slots	1.0000
Sena Graph Display	1.0000
Sena Harmonic Distortion	less than 2 %
Sena Heat Dissipation	535 Btu/h
Sena Input Voltage	120 V
Sena Input Voltage 1	120 V
Sena Ip Degree Of Protection	IP20
Sena Maximum Configurable Power In Va	2200 VA
Sena Maximum Configurable Power In W	1800 W
Sena Mounting Location	front
Sena Mounting Mode	rack-mounted
Sena Mounting Position	horizontal
Sena Mounting Preference	lower
Sena Nb Of Power Socket Outlets	1 NEMA L5-20R 6 NEMA 5-20R
Sena Network Frequency	40…70 Hz auto-sensing
Sena Number Of Battery Filled Slots	1.0000
Sena Number Of Battery Replacement Quantity	1.0000
Sena Number Of Cables	1.0000
Sena Number Of Power Module	1400.0000
Sena Number Of Rack Unit	2U
Sena Number Of Tare Power	26 W
Sena Operating Altitude	0…10000 ft
Sena Output Frequency	50/60 Hz ± 3 Hz sync to mains
Sena Output Voltage	120 V
Sena Output Voltage 1	120 V
Sena Performance Multiplier	1.0000
Sena Plug Standard	NEMA 5-20P
Sena Product Certifications	ENERGY STAR V2.0 (USA)
Sena Provided Equipment	CD with software documentation CD installation guide rack mounting brackets rack mounting hardware rack mounting support rails USB cable warranty card
Sena Provided Equipment 1	CD with software documentation CD installation guide rack mounting brackets rack mounting hardware rack mounting support rails USB cable warranty card
Sena Provided Equipment 2	CD with software documentation CD installation guide rack mounting brackets rack mounting hardware rack mounting support rails USB cable warranty card
Sena Rated Power In Va	2200 VA
Sena Rated Power In W	1800 W
Sena Redundant	No
Sena Relative Humidity	0-95 % non-condensing
Sena Show Note Op Temperature	No
Sena Size Ups Version	internetworking# #server# #telecom
Sena Standards	CSA C22.2 No 107.3-05# #FCC part 15 class A# #OSHPD# #UL 1778
Sena Storage Altitude	0-50000 ft
Sena Storage Relative Humidity	0-95 % non-condensing
Sena Surge Energy Rate	340 J
Sena Ups Design Life	7 year(s)
Sena Ups Size	S
Sena Ups Type	double conversion online
Sena Usb Compatible	Yes
Sena Value Multiplier	1.0000
Sena Wave Type	sine wave
