APC SMTL1000RM2UC

Name: APC SMTL1000RM2UC
Brand: APC
SKU: CS4805351
Availability: OutOfStock

SKU: CS4805351MPN: SMTL1000RM2UCUPC/EAN: 731304341987

APC Smart-UPS, Line Interactive, 1000VA, Lithium-ion, Rack/Tower, 2U, 120V, 6x NEMA 5-15R outlets, SmartConnect Port+SmartSlot, Short Depth, AVR, LCD

Product Details

APC Smart-UPS, Line Interactive, 1000VA, Lithium-ion, Rack/Tower, 2U, 120V, 6x NEMA 5-15R outlets, SmartConnect Port+SmartSlot, Short Depth, AVR, LCD

Attributes

Sena Acoustic Level	41 dBA
Sena Additional Specification	Lithium-Ion
Sena Alarm	alarm when on battery : distinctive low battery alarm : configurable delays
Sena Ambient Air Temperature For Operation	0-40 °C
Sena Ambient Air Temperature For Storage	-40-35 °C
Sena Battery Charger Power	79 W rated
Sena Battery Curve	D
Sena Battery Design Life	5-10 year(s)
Sena Battery Design Life 1	5-10 year(s)
Sena Battery Life	5-10 year(s)
Sena Battery Recharge Time	3 h
Sena Battery Type	Li-Ion (Lithium-Ion)
Sena Control Panel	multifunction LCD status and control console
Sena Curve Equation	efficiency
Sena Curve Fixed Loss	0.0062000001780689
Sena Curve Load Maximum	1.0000
Sena Curve Load Minimum	0.0099999997764826
Sena Curve Square Loss	0.0065000001341105
Sena Curve Test Cond Id	Curve fit of data measured in accordance with the US DOE Test Procedure for Uninterruptible Power Supplies. All measurements taken in normal mode(s), at typical environmental conditions, with 120V/60Hz electrical input and balanced resistive load (PF = 1.
Sena Curve X Axis Maximum	1.0000
Sena Curve X Axis Title	load
Sena Curve X Axis Units	percentage
Sena Curve Y Axis Maximum	1.0000
Sena Curve Y Axis Minimum	0.5000
Sena Curve Y Axis Title	efficiency
Sena Curve Y Axis Units	percentage
Sena Equipment Protection Policy	lifetime : $150000
Sena Free Slots	1.0000
Sena Graph Display	1.0000
Sena Harmonic Distortion	less than 5 %
Sena Heat Dissipation	70 Btu/h
Sena Input Voltage	120 V
Sena Input Voltage 1	120 V
Sena Input Voltage Limits	75…154 V adjustable 82…144 V
Sena Maximum Configurable Power In Va	1000 VA
Sena Maximum Configurable Power In W	800 W
Sena Mounting Location	front
Sena Mounting Mode	rack-mounted
Sena Mounting Preference	lower
Sena Nb Of Power Socket Outlets	6 NEMA 5-15R
Sena Network Frequency	50/60 Hz ± 3 Hz auto-sensing
Sena Noise Suppression	full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Sena Number Of Rack Unit	2U
Sena Number Of Tare Power	58 W
Sena Operating Altitude	0…10000 ft
Sena Output Frequency	50/60 Hz ± 3 Hz sync to mains
Sena Output Voltage	120 V
Sena Output Voltage 1	120 V
Sena Performance Multiplier	1.0000
Sena Plug Standard	NEMA 5-15P
Sena Product Certifications	NOM
Sena Provided Equipment	installation guide rack mounting support rails USB cable
Sena Provided Equipment 1	installation guide rack mounting support rails USB cable
Sena Provided Equipment 2	installation guide rack mounting support rails USB cable
Sena Rated Power In Va	1000 VA
Sena Rated Power In W	800 W
Sena Redundant	No
Sena Relative Humidity	0-95 % non-condensing
Sena Show Note Op Temperature	No
Sena Standards	CSA C22.2 No 107.3# #FCC part 15 class A# #UL 1778# #UL 1973
Sena Storage Altitude	0-25000 ft
Sena Storage Relative Humidity	0-95 % non-condensing
Sena Surge Energy Rate	680 J
Sena Transfer Time	6 ms typical : 10 ms maximum
Sena Two Post Mountable	1.0000
Sena Ups Design Life	10 year(s)
Sena Ups Size	S
Sena Ups Type	line interactive
Sena Usb Compatible	Yes
Sena Value Multiplier	1.0000
Sena Wave Type	sine wave
