APC SMT3000RM2UC

Name: APC SMT3000RM2UC
Brand: APC
SKU: CS4805343
Availability: OutOfStock

SKU: CS4805343MPN: SMT3000RM2UCUPC/EAN: 731304331070

APC Smart-UPS, Line Interactive, 3kVA, Rackmount 2U, 120V, 6x NEMA 5-15R+2x NEMA 5-20R outlets, SmartConnect Port+SmartSlot, AVR, LCD

Documents

APC, Square D SMT1000C, SMT1000RM2UC, SMT2200C, SMT3000RM2UC, SMT750C, SMT750RM2UC Manual

Product Details

APC Smart-UPS 3000VA LCD RM 2U 120V with SmartConnect

Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices

Includes: CD with software, Documentation CD, Rack Mounting brackets, Rack Mounting support rails, Smart UPS signaling RS-232 cable, USB cable

Attributes

Sena Acoustic Level	55 dBA
Sena Additional Specification	cloud-enabled monitoring
Sena Alarm	alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Sena Ambient Air Temperature For Operation	0-40 °C
Sena Ambient Air Temperature For Storage	-15-45 °C
Sena Battery Charger Power	172 W rated
Sena Battery Curve	C
Sena Battery Life	3-5 year(s)
Sena Battery Recharge Time	3 h
Sena Battery Type	lead-acid battery
Sena Control Panel	LED status display with on line : on battery : replace battery and overload indicators# #multifunction LCD status and control console
Sena Curve Equation	efficiency
Sena Curve Fixed Loss	0.0020000000949949
Sena Curve Load Maximum	1.0000
Sena Curve Load Minimum	0.0099999997764826
Sena Curve Square Loss	0.01549999974668
Sena Curve Test Cond Id	Curve fit of data measured in accordance with the ENERGY STAR Test Method for Uninterruptible Power Supplies. All measurements taken in normal mode(s), at typical environmental conditions, with 120V/60Hz electrical input and balanced resistive load (PF =
Sena Curve X Axis Maximum	1.0000
Sena Curve X Axis Title	load
Sena Curve X Axis Units	percentage
Sena Curve Y Axis Maximum	1.0000
Sena Curve Y Axis Minimum	0.5000
Sena Curve Y Axis Title	efficiency
Sena Curve Y Axis Units	percentage
Sena Equipment Protection Policy	lifetime : $150000
Sena Free Slots	1.0000
Sena Graph Display	1.0000
Sena Harmonic Distortion	less than 5 %
Sena Heat Dissipation	348 Btu/h
Sena Input Voltage	120 V
Sena Input Voltage 1	120 V
Sena Input Voltage Limits	75…154 V adjustable 82…144 V
Sena Maximum Configurable Power In Va	2880 VA
Sena Maximum Configurable Power In W	2700 W
Sena Mounting Location	front
Sena Mounting Mode	rack-mounted
Sena Mounting Preference	lower
Sena Nb Of Power Socket Outlets	2 NEMA 5-20R 6 NEMA 5-15R
Sena Network Frequency	50/60 Hz ± 3 Hz auto-sensing
Sena Number Of Battery Replacement Quantity	1.0000
Sena Number Of Cables	1.0000
Sena Number Of Rack Unit	2U
Sena Number Of Tare Power	41 W
Sena Operating Altitude	0…10000 ft
Sena Output Frequency	50/60 Hz ± 3 Hz sync to mains
Sena Output Voltage	120 V
Sena Output Voltage 1	120 V
Sena Performance Multiplier	1.0000
Sena Plug Standard	NEMA L5-30P
Sena Product Certifications	cULus# #ENERGY STAR V2.0 (USA)
Sena Provided Equipment	documentation CD installation guide rack mounting hardware rack mounting support rails Smart UPS signalling RS-232 cable USB cable
Sena Provided Equipment 1	documentation CD installation guide rack mounting hardware rack mounting support rails Smart UPS signalling RS-232 cable USB cable
Sena Provided Equipment 2	documentation CD installation guide rack mounting hardware rack mounting support rails Smart UPS signalling RS-232 cable USB cable
Sena Rated Power In Va	2880 VA
Sena Rated Power In W	2700 W
Sena Redundant	No
Sena Relative Humidity	0-95 %
Sena Show Note Op Temperature	No
Sena Standards	CSA C22.2 No 107.1# #FCC part 15 class A# #UL 1778
Sena Storage Altitude	0-50000 ft
Sena Storage Relative Humidity	0-95 %
Sena Surge Energy Rate	459 J
Sena Transfer Time	6 ms typical : 10 ms maximum
Sena Ups Design Life	6 year(s)
Sena Ups Size	S
Sena Ups Type	line interactive
Sena Usb Compatible	Yes
Sena Value Multiplier	1.0000
Sena Wave Type	sine wave
