APC SMC1000C

Name: APC SMC1000C
Brand: APC
SKU: CS3671062
Availability: OutOfStock

SKU: CS3671062MPN: SMC1000CAlternate Part #: APC-SMC1000CUPC/EAN: 731304322740

APC Smart-UPS C, Line Interactive, 1000VA, Tower, 120V, 8x NEMA 5-15R outlets, SmartConnect port, USB and Serial communication, AVR, Graphic LCD

Documents

APC Manual

Product Details

APC Smart-UPS C 1000VA LCD 120V with SmartConnect

Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.

Includes: CD with software , Documentation CD , USB cable

Attributes

Sena Acoustic Level	41 dBA
Sena Additional Specification	cloud-enabled monitoring
Sena Alarm	alarm when on battery : distinctive low battery alarm : configurable delays
Sena Ambient Air Temperature For Operation	0-40 °C
Sena Ambient Air Temperature For Storage	-15-45 °C
Sena Battery Charger Power	72 W rated
Sena Battery Curve	C
Sena Battery Life	3-5 year(s)
Sena Battery Recharge Time	3 h
Sena Battery Type	lead-acid battery
Sena Control Panel	multifunction LCD status and control console
Sena Curve Equation	efficiency
Sena Curve Fixed Loss	0.0059000002220273
Sena Curve Load Maximum	1.0000
Sena Curve Load Minimum	0.0099999997764826
Sena Curve Square Loss	0.0041999998502433
Sena Curve Test Cond Id	Curve fit of data measured in accordance with the US DOE Test Procedure for Uninterruptible Power Supplies. All measurements taken in normal mode(s), at typical environmental conditions, with 125V/60Hz electrical input and balanced resistive load (PF = 1.
Sena Curve X Axis Maximum	1.0000
Sena Curve X Axis Title	load
Sena Curve X Axis Units	percentage
Sena Curve Y Axis Maximum	1.0000
Sena Curve Y Axis Minimum	0.5000
Sena Curve Y Axis Title	efficiency
Sena Curve Y Axis Units	percentage
Sena Equipment Protection Policy	lifetime : $150000
Sena Graph Display	1.0000
Sena Harmonic Distortion	less than 5 %
Sena Heat Dissipation	175 Btu/h
Sena Input Voltage	120 V
Sena Input Voltage 1	120 V
Sena Input Voltage Limits	85…136 V adjustable 93…130 V
Sena Maximum Configurable Power In Va	1000 VA
Sena Maximum Configurable Power In W	600 W
Sena Mounting Location	front
Sena Mounting Mode	not rack-mountable
Sena Mounting Preference	no preference
Sena Nb Of Power Socket Outlets	8 NEMA 5-15R
Sena Network Frequency	50/60 Hz ± 3 Hz auto-sensing
Sena Noise Suppression	full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Sena Number Of Battery Replacement Quantity	1.0000
Sena Number Of Cables	1.0000
Sena Number Of Tare Power	45 W
Sena Operating Altitude	0…10000 ft
Sena Output Frequency	50/60 Hz ± 3 Hz sync to mains
Sena Output Voltage	120 V
Sena Output Voltage 1	120 V
Sena Performance Multiplier	1.0000
Sena Plug Standard	NEMA 5-15P
Sena Product Certifications	cULus# #ENERGY STAR V2.0 (USA)
Sena Provided Equipment	USB cable
Sena Provided Equipment 1	USB cable
Sena Provided Equipment 2	USB cable
Sena Rated Power In Va	1000 VA
Sena Rated Power In W	600 W
Sena Redundant	No
Sena Relative Humidity	0-95 %
Sena Show Note Op Temperature	No
Sena Size Ups Version	internetworking# #server# #telecom
Sena Standards	CSA C22.2 No 107.1# #FCC part 15 class A# #ICES-003# #UL 1778
Sena Storage Altitude	0-50000 ft
Sena Storage Relative Humidity	0-95 %
Sena Surge Energy Rate	680 J
Sena Transfer Time	6 ms typical : 10 ms maximum
Sena Ups Design Life	5 year(s)
Sena Ups Size	S
Sena Ups Type	line interactive
Sena Usb Compatible	Yes
Sena Value Multiplier	1.0000
Sena Wave Type	sine wave
