APC SMT1500RM1U

Name: APC SMT1500RM1U
Brand: APC
SKU: CS4805335
Availability: OutOfStock

SKU: CS4805335MPN: SMT1500RM1UUPC/EAN: 731304299394

APC Smart-UPS, Line Interactive, 1500VA, Rackmount 1U, 120V, 4x NEMA 5-15R outlets, SmartSlot, AVR, LCD, Not for sale in the US

Documents

APC SMT1500RM1U Manual

Product Details

APC Smart-UPS 1500VA LCD RM 1U 120V

APC Smart-UPS,1000 Watts /1440 VA,Input 120V /Output 120V, Interface Port RJ-45 Serial, SmartSlot, USB, Rack Height 1 U

Includes: CD with software, Documentation CD, Installation guide, Rack Mounting support rails, Smart UPS signalling RS-232 cable, USB cable, Warranty card

Attributes

Sena Acoustic Level	46 dBA
Sena Alarm	alarm when on battery : distinctive low battery alarm : configurable delays
Sena Ambient Air Temperature For Operation	0-40 °C
Sena Ambient Air Temperature For Storage	-15-45 °C
Sena Battery Charger Power	73 W rated
Sena Battery Curve	B
Sena Battery Life	3-5 year(s)
Sena Battery Recharge Time	4 h
Sena Battery Type	lead-acid battery
Sena Control Panel	multifunction LCD status and control console
Sena Curve Equation	efficiency
Sena Curve Fixed Loss	0.0118
Sena Curve Load Maximum	1.0000
Sena Curve Load Minimum	0.0200
Sena Curve Square Loss	0.0063
Sena Curve Test Cond Id	Curve fit of data measured in accordance with the US DOE Test Procedure for Uninterruptible Power Supplies. All measurements taken in normal mode(s), at typical environmental conditions, with 120V/60Hz electrical input and balanced resistive load (PF = 1.
Sena Curve X Axis Maximum	1.0000
Sena Curve X Axis Title	load
Sena Curve X Axis Units	percentage
Sena Curve Y Axis Maximum	1.0000
Sena Curve Y Axis Minimum	0.5000
Sena Curve Y Axis Title	efficiency
Sena Curve Y Axis Units	percentage
Sena Equipment Protection Policy	lifetime : $150000
Sena Free Slots	1.0000
Sena Graph Display	1.0000
Sena Harmonic Distortion	less than 5 %
Sena Heat Dissipation	88 Btu/h
Sena Input Voltage	120 V
Sena Input Voltage 1	120 V
Sena Maximum Configurable Power In Va	1440 VA
Sena Maximum Configurable Power In W	1000 W
Sena Mounting Location	front
Sena Mounting Mode	rack-mounted
Sena Mounting Preference	lower
Sena Nb Of Power Socket Outlets	4 NEMA 5-15R
Sena Network Frequency	50/60 Hz ± 3 Hz auto-sensing
Sena Noise Suppression	full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Sena Number Of Battery Replacement Quantity	1.0000
Sena Number Of Rack Unit	1U
Sena Number Of Tare Power	17 W
Sena Operating Altitude	0…10000 ft
Sena Output Frequency	50/60 Hz ± 3 Hz sync to mains
Sena Output Voltage	120 V
Sena Output Voltage 1	120 V
Sena Performance Multiplier	1.0000
Sena Plug Standard	NEMA 5-15P
Sena Product Certifications	CSA
Sena Provided Equipment	CD with software documentation CD installation guide rack mounting support rails Smart UPS signalling RS-232 cable USB cable warranty card
Sena Provided Equipment 1	CD with software documentation CD installation guide rack mounting support rails Smart UPS signalling RS-232 cable USB cable warranty card
Sena Provided Equipment 2	CD with software documentation CD installation guide rack mounting support rails Smart UPS signalling RS-232 cable USB cable warranty card
Sena Rated Power In Va	1440 VA
Sena Rated Power In W	1000 W
Sena Redundant	No
Sena Relative Humidity	0-95 %
Sena Show Note Op Temperature	No
Sena Standards	FCC part 15 class A# #UL 1778
Sena Storage Altitude	0-50000 ft
Sena Storage Relative Humidity	0-95 %
Sena Surge Energy Rate	540 J
Sena Transfer Time	4 ms typical : 8 ms maximum
Sena Ups Design Life	6 year(s)
Sena Ups Size	S
Sena Ups Type	line interactive
Sena Usb Compatible	No
Sena Value Multiplier	1.0000
Sena Wave Type	sine wave
