APC BK500EI

Name: APC BK500EI
Brand: APC
SKU: CS4805255
Availability: OutOfStock

SKU: CS4805255MPN: BK500EIUPC/EAN: 731304016359

APC Back-UPS CS 500VA, 230V, 4 IEC outlets

Documents

APC BK350EI, BK500EI Manual

Product Details

APC Back-UPS 500, 230V

APC Back-UPS,300 Watts /500 VA,Input 230V /Output 230V, Interface Port Optional Simple Signalling RS232 cable, USB

Includes: CD with software, Documentation CD, Qty 1 - Detachable 1.2 m IEC power cord, Qty 1 - Detachable 1.8 m IEC power cord, Telephone Cable, USB cable, Warranty card

Attributes

Sena Acoustic Level	40 dBA
Sena Alarm	alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Sena Ambient Air Temperature For Operation	0-40 °C
Sena Ambient Air Temperature For Storage	-15-45 °C
Sena Battery Capacity	7.0 Ah
Sena Battery Charger Power	10 W rated
Sena Battery Curve	B
Sena Battery Life	4-6 year(s)
Sena Battery Recharge Time	8 h
Sena Battery Type	lead-acid battery
Sena Battery Voltage	12 V
Sena Control Panel	LED status display with on line : on battery : replace battery and overload indicators
Sena Curve Equation	efficiency
Sena Curve Fixed Loss	0.0093
Sena Curve Load Maximum	1.0000
Sena Curve Load Minimum	0.0100
Sena Curve Square Loss	0.0012
Sena Curve Test Cond Id	Curve fit of data measured in accordance with the ENERGY STAR Test Method for Uninterruptible Power Supplies. All measurements taken in normal mode(s), at typical environmental conditions, with 230V/50Hz electrical input and balanced resistive load (PF =
Sena Curve X Axis Maximum	1.0000
Sena Curve X Axis Title	load
Sena Curve X Axis Units	percentage
Sena Curve Y Axis Maximum	1.0000
Sena Curve Y Axis Minimum	0.5000
Sena Curve Y Axis Title	efficiency
Sena Curve Y Axis Units	percentage
Sena Data Line Protection	RJ45 analog phone line for phone/fax/modem/DSL
Sena Graph Display	1.0000
Sena Heat Dissipation	24 Btu/h
Sena Input Voltage	230 V
Sena Input Voltage 1	230 V
Sena Input Voltage Limits	160…300 V adjustable 180…266 V
Sena Max Runtime	45 min
Sena Maximum Configurable Power In Va	500 VA
Sena Maximum Configurable Power In W	300 W
Sena Maximum Input Current	0.2916666666666667
Sena Mounting Location	front
Sena Mounting Mode	not rack-mountable
Sena Mounting Preference	no preference
Sena Nb Of Power Socket Outlets	1 IEC 60320 C13 surge 2 IEC Jumpers surge 3 IEC 60320 C13
Sena Network Frequency	47…63 Hz 50/60 Hz ± 3 Hz auto-sensing
Sena Noise Suppression	full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449
Sena Number Of Battery Replacement Quantity	1.0000
Sena Number Of Cables	2.0000
Sena Number Of Tare Power	14 W
Sena Operating Altitude	0…10000 ft
Sena Output Frequency	47…63 Hz sync to mains 50/60 Hz ± 1 Hz unsynchronised
Sena Output Voltage	230 V
Sena Output Voltage 1	230 V
Sena Performance Multiplier	1.0000
Sena Plug Standard	IEC 60320 C14
Sena Product Certifications	C-Tick# #CE# #GOST# #VDE
Sena Provided Equipment	1 x detachable 1.2 m IEC power cord 1 x detachable IEC power cord CD with software documentation CD telephone cable USB cable warranty card
Sena Provided Equipment 1	1 x detachable 1.2 m IEC power cord 1 x detachable IEC power cord CD with software documentation CD telephone cable USB cable warranty card
Sena Provided Equipment 2	1 x detachable 1.2 m IEC power cord 1 x detachable IEC power cord CD with software documentation CD telephone cable USB cable warranty card
Sena Rated Power In Va	500 VA
Sena Rated Power In W	300 W
Sena Redundant	No
Sena Relative Humidity	0-95 %
Sena Show Note Op Temperature	No
Sena Size Ups Version	internetworking# #workstation
Sena Standards	EN 50091-1# #EN 50091-2
Sena Storage Altitude	0-50000 ft
Sena Storage Relative Humidity	0-95 %
Sena Surge Energy Rate	310 J
Sena Switching Current Capacity	0.2916666666666667
Sena Transfer Time	6 ms typical : 10 ms maximum
Sena Ups Size	WS
Sena Ups Type	standby
Sena Usb Compatible	No
Sena Value Multiplier	1.0000
Sena Wave Type	stepped approximation to a sinewave
