APC SRT5KRMXLI

Name: APC SRT5KRMXLI
Brand: APC
SKU: CS4805384
Availability: OutOfStock

SKU: CS4805384MPN: SRT5KRMXLIUPC/EAN: 731304301196

APC Smart-UPS On-Line, 5kVA, Rackmount 3U, 230V, 6x C13+4x C19 IEC outlets, Network Card+SmartSlot, Extended runtime, W/ rail kit

Product Details

APC Smart-UPS SRT 5000VA RM 230V

Attributes

Sena Acoustic Level	55 dBA
Sena Additional Specification	high density
Sena Alarm	audible and visible alarms prioritized by severity
Sena Ambient Air Temperature For Operation	0-40 °C
Sena Ambient Air Temperature For Storage	-15-45 °C
Sena Battery Charger Power	560 W rated
Sena Battery Curve	D
Sena Battery Life	3-5 year(s)
Sena Battery Option	SRT192RMBP 1 2535 VAh SRT192RMBP 10 17745 VAh SRT192RMBP 2 4225 VAh SRT192RMBP 3 5915 VAh SRT192RMBP 4 7605 VAh SRT192RMBP 5 9295 VAh SRT192RMBP 6 10985 VAh SRT192RMBP 8 14365 VAh
Sena Battery Recharge Time	1.5 h
Sena Battery Type	lead-acid battery
Sena Battery Voltage	192 V
Sena Bypass Type	internal bypass (automatic and manual)
Sena Control Panel	multifunction LCD status and control console
Sena Crest Factor	0.12569444444444444
Sena Curve Equation	efficiency
Sena Curve Fixed Loss	0.0142
Sena Curve Load Maximum	1.0000
Sena Curve Load Minimum	0.0200
Sena Curve Proportional Loss	0.0236
Sena Curve Square Loss	0.0247
Sena Curve Test Cond Id	Curve fit of data measured in accordance with the ENERGY STAR Test Method for Uninterruptible Power Supplies. All measurements taken in normal mode(s), at typical environmental conditions, with 230V/50Hz electrical input and balanced resistive load (PF =
Sena Curve X Axis Maximum	1.0000
Sena Curve X Axis Title	load
Sena Curve X Axis Units	percentage
Sena Curve Y Axis Maximum	1.0000
Sena Curve Y Axis Minimum	0.5000
Sena Curve Y Axis Title	efficiency
Sena Curve Y Axis Units	percentage
Sena Emergency Power Off	yes
Sena Extended Runtime	1.0000
Sena Free Slots	1.0000
Sena Graph Display	1.0000
Sena Harmonic Distortion	less than 2 %
Sena Heat Dissipation	931 Btu/h
Sena Input Voltage	230 V
Sena Input Voltage 1	230 V
Sena Input Voltage Limits	100…275 V adjustable (half load)
Sena Ip Degree Of Protection	IP20
Sena Maximum Configurable Power In Va	5000 VA
Sena Maximum Configurable Power In W	4500 W
Sena Mounting Location	front
Sena Mounting Mode	rack-mounted
Sena Mounting Position	horizontal
Sena Mounting Preference	no preference
Sena Nb Of Power Socket Outlets	2 IEC Jumpers 4 IEC 60320 C19 6 IEC 60320 C13
Sena Network Frequency	40…70 Hz auto-sensing
Sena Number Of Battery Replacement Quantity	1.0000
Sena Number Of Input Connectors	1 hard wire 3-wire (1P + N + E)
Sena Number Of Rack Unit	3U
Sena Number Of Tare Power	78 W
Sena Operating Altitude	0…10000 ft
Sena Output Frequency	50/60 Hz ± 3 Hz sync to mains
Sena Output Voltage	230 V
Sena Output Voltage 1	230 V
Sena Product Certifications	CE# #EAC# #IRAM# #RCM# #VDE
Sena Provided Equipment	documentation CD installation guide rack mounting brackets rack mounting hardware rack mounting support rails temperature probe warranty card web/SNMP management card
Sena Provided Equipment 1	documentation CD installation guide rack mounting brackets rack mounting hardware rack mounting support rails temperature probe warranty card web/SNMP management card
Sena Provided Equipment 2	documentation CD installation guide rack mounting brackets rack mounting hardware rack mounting support rails temperature probe warranty card web/SNMP management card
Sena Rated Power In Va	5000 VA
Sena Rated Power In W	4500 W
Sena Redundant	No
Sena Relative Humidity	0-95 % non-condensing
Sena Show Note Op Temperature	No
Sena Standards	EN/IEC 62040-1# #EN/IEC 62040-2
Sena Storage Altitude	0-50000 ft
Sena Storage Relative Humidity	0-95 % non-condensing
Sena Surge Energy Rate	480 J
Sena Ups Design Life	7 year(s)
Sena Ups Size	S
Sena Ups Type	double conversion online
Sena Usb Compatible	Yes
Sena Wave Type	sine wave
