APC SMT1500I

Name: APC SMT1500I
Brand: APC
SKU: CS3666258
Availability: OutOfStock

SKU: CS3666258MPN: SMT1500IAlternate Part #: APC-SMT1500IUPC/EAN: 731304268680

APC Smart-UPS, Line Interactive, 1500VA, Tower, 230V, 8x IEC C13 outlets, SmartSlot, AVR, LCD

Discontinued - Contact Us For Pricing & Availability

Product Details

APC Smart-UPS 1500VA LCD 230V

Attributes

Sena Acoustic Level	45 dBA
Sena Additional Information	Configurable for 220 : 230 or 240 nominal output voltage
Sena Alarm	alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Sena Ambient Air Temperature For Operation	0-40 °C
Sena Ambient Air Temperature For Storage	-15-45 °C
Sena Battery Charger Power	136 W rated
Sena Battery Curve	Z
Sena Battery Life	3-5 year(s)
Sena Battery Recharge Time	3 h
Sena Battery Type	lead-acid battery
Sena Control Panel	multifunction LCD status and control console
Sena Curve Equation	efficiency
Sena Curve Fixed Loss	0.0101
Sena Curve Load Maximum	1.0000
Sena Curve Load Minimum	0.0200
Sena Curve Square Loss	0.0034
Sena Curve Test Cond Id	Curve fit of data measured in accordance with the ENERGY STAR Test Method for Uninterruptible Power Supplies. All measurements taken in normal mode(s), at typical environmental conditions, with 230V/50Hz electrical input and balanced resistive load (PF =
Sena Curve X Axis Maximum	1.0000
Sena Curve X Axis Title	load
Sena Curve X Axis Units	percentage
Sena Curve Y Axis Maximum	1.0000
Sena Curve Y Axis Minimum	0.5000
Sena Curve Y Axis Title	efficiency
Sena Curve Y Axis Units	percentage
Sena Free Slots	1.0000
Sena Graph Display	1.0000
Sena Harmonic Distortion	less than 5 % at full load
Sena Heat Dissipation	135 Btu/h
Sena Input Voltage	230 V
Sena Input Voltage 1	230 V
Sena Input Voltage Limits	151…302 V adjustable 160…286 V
Sena Maximum Configurable Power In Va	1500 VA
Sena Maximum Configurable Power In W	1000 W
Sena Mounting Location	front
Sena Mounting Mode	not rack-mountable
Sena Mounting Preference	no preference
Sena Nb Of Power Socket Outlets	2 IEC Jumpers 8 IEC 320 C13
Sena Network Frequency	50/60 Hz ± 3 Hz auto-sensing
Sena Noise Suppression	full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Sena Number Of Battery Replacement Quantity	1.0000
Sena Number Of Cables	1.0000
Sena Number Of Tare Power	30 W
Sena Operating Altitude	0…10000 ft
Sena Output Frequency	47…53 Hz for 50 Hz nominal sync to mains 57…63 Hz for 60 Hz nominal sync to mains
Sena Output Voltage	230 V
Sena Output Voltage 1	230 V
Sena Performance Multiplier	1.0000
Sena Plug Standard	IEC 320 C14
Sena Product Certifications	CE# #EAC# #RCM# #VDE
Sena Provided Equipment	CD with software documentation CD installation guide Smart UPS signalling RS-232 cable USB cable
Sena Provided Equipment 1	CD with software documentation CD installation guide Smart UPS signalling RS-232 cable USB cable
Sena Provided Equipment 2	CD with software documentation CD installation guide Smart UPS signalling RS-232 cable USB cable
Sena Rated Power In Va	1500 VA
Sena Rated Power In W	1000 W
Sena Redundant	No
Sena Relative Humidity	0-95 %
Sena Show Note Op Temperature	No
Sena Size Ups Version	internetworking# #server# #telecom
Sena Standards	EN/IEC 62040-1# #EN/IEC 62040-2
Sena Storage Altitude	0-50000 ft
Sena Storage Relative Humidity	0-95 %
Sena Surge Energy Rate	459 J
Sena Ups Size	S
Sena Ups Type	line interactive
Sena Usb Compatible	No
Sena Value Multiplier	1.0000
Sena Wave Type	sine wave
