APC BGE50ML

Name: APC BGE50ML
Brand: APC
SKU: CS4805252
Availability: OutOfStock

SKU: CS4805252MPN: BGE50MLUPC/EAN: 731304314097

APC Back-UPS Connect 50 Lithium Ion Network UPS, Mobile Power Bank 120V

Documents

APC BGE50ML Manual

Product Details

APC Back-UPS Connect 50, 120V, Lithium Ion, Network Backup and Mobile Power Pack

Extended Runtime UPS for Network Gateway Devices

br>Includes: Country-specific detachable power cord, Removable Mobile Power Pack, Removable support feet, Stabilization / Wall mounting feet, USB cable, User Manual

Attributes

Sena Acoustic Level	32 dBA
Sena Ambient Air Temperature For Operation	0-40 °C
Sena Ambient Air Temperature For Storage	-15-45 °C
Sena Battery Charger Power	14 W rated
Sena Battery Curve	L1
Sena Battery Life	2-4 year(s)
Sena Battery Recharge Time	2.5 h
Sena Battery Type	Li-Ion (Lithium-Ion)
Sena Control Panel	LED Status display with on line : on battery
Sena Curve Equation	efficiency
Sena Curve Fixed Loss	0.0675
Sena Curve Load Maximum	1.0000
Sena Curve Load Minimum	0.0700
Sena Curve Square Loss	0.0007
Sena Curve Test Cond Id	Curve fit of data measured in accordance with the US DOE Test Procedure for Uninterruptible Power Supplies. All measurements taken in normal mode(s), at typical environmental conditions, with 120V/60Hz electrical input and balanced resistive load (PF = 1.
Sena Curve X Axis Maximum	1.0000
Sena Curve X Axis Title	load
Sena Curve X Axis Units	percentage
Sena Curve Y Axis Maximum	1.0000
Sena Curve Y Axis Minimum	0.5000
Sena Curve Y Axis Title	efficiency
Sena Curve Y Axis Units	percentage
Sena Graph Display	1.0000
Sena Graph Start Point	10.0000
Sena Input Voltage	120 V
Sena Input Voltage 1	120 V
Sena Input Voltage Limits	92…139 V
Sena Let Through Voltage Rating	800 V
Sena Maximum Configurable Power In Va	84 VA
Sena Maximum Configurable Power In W	50 W
Sena Maximum Input Current	0.08333333333333333
Sena Mounting Location	side
Sena Mounting Mode	rack-mounted
Sena Mounting Position	vertical
Sena Mounting Preference	no preference
Sena Mounting Support	wall
Sena Nb Of Power Socket Outlets	2 NEMA 5-15R
Sena Network Frequency	50/60 Hz ± 3 Hz auto-sensing
Sena Number Of Cables	1.0000
Sena Number Of Tare Power	1 W
Sena Operating Altitude	0…10000 ft
Sena Output Frequency	50/60 Hz ± 3 Hz sync to mains
Sena Output Voltage	120 V
Sena Output Voltage 1	120 V
Sena Plug Standard	NEMA 5-15P
Sena Product Certifications	California Energy Commission (CEC)# #cTUVus# #UN 38.3
Sena Provided Equipment	country-specific detachable power cord removable mobile power pack removable support feet stabilization/wall mounting feet USB cable user manual
Sena Provided Equipment 1	country-specific detachable power cord removable mobile power pack removable support feet stabilization/wall mounting feet USB cable user manual
Sena Provided Equipment 2	country-specific detachable power cord removable mobile power pack removable support feet stabilization/wall mounting feet USB cable user manual
Sena Rated Power In Va	84 VA
Sena Rated Power In W	50 W
Sena Redundant	No
Sena Relative Humidity	0-95 % non-condensing
Sena Show Note Op Temperature	No
Sena Standards	EN 55022 class A# #EN 55024# #EN 61000-3-2# #EN 61000-3-3# #EN 61000-4-8# #EN 61000-4-2# #EN 61000-4-3# #FCC part 15 class B# #ICES-003
Sena Storage Altitude	0-50000 ft
Sena Storage Relative Humidity	0-95 % non-condensing
Sena Surge Energy Rate	340 J
Sena Switching Current Capacity	0.16666666666666666
Sena Transfer Time	8 ms typical : 10 ms maximum
Sena Ups Size	WS
Sena Ups Type	standby
Sena Usb Compatible	No
Sena Wave Type	stepped approximation to a sinewave
