APC SMX1000

Name: APC SMX1000
Brand: APC
SKU: CS4805354
Availability: OutOfStock

SKU: CS4805354MPN: SMX1000UPC/EAN: 731304268574

APC Smart-UPS X 1000VA Rack/Tower LCD 120V (Not for sale in CO, VT or WA)

Documents

APC AR3155, SMT2200R2X106, SMT3000RMT2U, SMX1000, SMX3000RMLV2U Manual

Product Details

APC Smart-UPS X 1000VA Rack/Tower LCD 120V

APC Smart-UPS,800 Watts /1000 VA,Input 120V /Output 120V, Interface Port SmartSlot, USB, Extended runtime model, Rack Height 2 U

Includes: CD with software, Documentation CD, Installation guide, Rack Mounting brackets, Removable support feet, Smart UPS signalling RS-232 cable, USB cable

Attributes

Sena Acoustic Level	40 dBA
Sena Additional Specification	extended run
Sena Alarm	alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Sena Ambient Air Temperature For Operation	0-40 °C
Sena Ambient Air Temperature For Storage	-15-45 °C
Sena Battery Charger Power	99 W rated
Sena Battery Curve	B
Sena Battery Life	3-5 year(s)
Sena Battery Option	SMX48RMBP2U 1 900 VAh SMX48RMBP2U 2 1500 VAh SMX48RMBP2U 3 2100 VAh SMX48RMBP2U 4 2700 VAh SMX48RMBP2U 5 3300 VAh
Sena Battery Recharge Time	3 h
Sena Battery Type	lead-acid battery
Sena Control Panel	multifunction LCD status and control console
Sena Curve Equation	efficiency
Sena Curve Fixed Loss	0.0125
Sena Curve Load Maximum	1.0000
Sena Curve Load Minimum	0.0200
Sena Curve Square Loss	0.0083
Sena Curve Test Cond Id	Curve fit of data measured in accordance with the US DOE Test Procedure for Uninterruptible Power Supplies. All measurements taken in normal mode(s), at typical environmental conditions, with 120V/60Hz electrical input and balanced resistive load (PF = 1.
Sena Curve X Axis Maximum	1.0000
Sena Curve X Axis Title	load
Sena Curve X Axis Units	percentage
Sena Curve Y Axis Maximum	1.0000
Sena Curve Y Axis Minimum	0.5000
Sena Curve Y Axis Title	efficiency
Sena Curve Y Axis Units	percentage
Sena Emergency Power Off	yes
Sena Equipment Protection Policy	lifetime : $150000
Sena Free Slots	1.0000
Sena Graph Display	1.0000
Sena Harmonic Distortion	less than 5 %
Sena Heat Dissipation	82 Btu/h
Sena Input Voltage	120 V
Sena Input Voltage 1	120 V
Sena Input Voltage Limits	82…143 V
Sena Maximum Configurable Power In Va	1000 VA
Sena Maximum Configurable Power In W	800 W
Sena Mounting Mode	rack-mounted with kit
Sena Mounting Preference	lower
Sena Nb Of Power Socket Outlets	8 NEMA 5-15R
Sena Network Frequency	50/60 Hz ± 3 Hz auto-sensing
Sena Noise Suppression	full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449
Sena Number Of Battery Replacement Quantity	1.0000
Sena Number Of Cables	1.0000
Sena Number Of Rack Unit	2U
Sena Number Of Tare Power	7 W
Sena Operating Altitude	0…10000 ft
Sena Output Frequency	50/60 Hz ± 3 Hz sync to mains
Sena Output Voltage	120 V
Sena Output Voltage 1	120 V
Sena Overcurrent Protection	60 A
Sena Performance Multiplier	1.0000
Sena Plug Standard	NEMA 5-15P
Sena Product Certifications	cUL listed
Sena Provided Equipment	CD with software documentation CD installation guide rack mounting brackets removable support feet Smart UPS signalling RS-232 cable USB cable
Sena Provided Equipment 1	CD with software documentation CD installation guide rack mounting brackets removable support feet Smart UPS signalling RS-232 cable USB cable
Sena Provided Equipment 2	CD with software documentation CD installation guide rack mounting brackets removable support feet Smart UPS signalling RS-232 cable USB cable
Sena Rated Power In Va	1000 VA
Sena Rated Power In W	800 W
Sena Redundant	No
Sena Relative Humidity	0-95 %
Sena Show Note Op Temperature	No
Sena Standards	UL 1778
Sena Storage Altitude	0-50000 ft
Sena Storage Relative Humidity	0-95 %
Sena Surge Energy Rate	600 J
Sena Switching Current Capacity	15 A
Sena Two Post Mountable	1.0000
Sena Ups Design Life	6 year(s)
Sena Ups Size	S
Sena Ups Type	line interactive
Sena Usb Compatible	Yes
Sena Value Multiplier	1.0000
Sena Wave Type	sine wave
