Carrier ZR16M3E-TWD-922

Name: Carrier ZR16M3E-TWD-922
Brand: Carrier
SKU: CS4231113
Price: 8756.35 USD
Availability: OutOfStock

SKU: CS4231113MPN: ZR16M3E-TWD-922Alternate Part #: CAR-ZR16M3E-TWD-922UPC/EAN: 822529541006

Copeland - ZR16M3E-TWD-922 160000 BTUh Scroll Compressor R-22

Carrier ZR16M3E TWC 922, ZR16M3E TWD 922, ZR16M3E TWD 961

Product Details

Copeland - ZR16M3E-TWD-922 is a Copeland Scroll™ Compressor that is three phase with a voltage of 460 VAC. The compressor is designed to work in units that are compatible with a BTU Output of 160,000 and use R-22 refrigerant.

Attributes

Amps	27.2
Phase	Three
Voltage	380-420/460 VAC
Oil Type	Polyolester (POE)
UL Listed	Yes
BTU Output	154,000
Protection	External Electronic Protection
Cycle/Hertz	50/60 Hz
Refrigerant	R-134a; R-22; R-407C
Displacement	12.47 (in^3/Rev)
Compressor Type	Scroll
Sound Level (dBA)	83
Compressor Housing	Hermetic
Liquid Temperature	85°F to 115°F (29.44°C to 46.11°C)
Mass Flow (lbs/hr)	2260 lbs./hr.; 2340 lbs./hr.
Mounting Dimensions	8.65” x 8.65” x 21.7”
Rated Load Amps (RLA)	27.2
Substantial Commodity	Steel
Condensing Temperature	100°F to 130°F (37.78°C to 54.44°C)
Return Gas Temperature	65°F (18.33°C)
Suction Line Size (OD)	1 ⅜”
Evaporating Temperature	45°F (7.22°C)
Locked Rotor Amps (LRA)	158
Oil Charge Initial (oz.)	140
Discharge Connection Type	Stub
Suction Line Fitting Type	Stub
Discharge Connection Size (OD)	⅞”
