Carrier ZP235KCE TED 750

Name: Carrier ZP235KCE TED 750
Brand: Carrier
SKU: CS4231022
Availability: OutOfStock

SKU: CS4231022MPN: ZP235KCE TED 750Alternate Part #: CAR-ZP235KCE-TED-750UPC/EAN: 822529632322

Factory Authorized Parts™ - ZP235KCE-TED-750 - Compressor Scroll

Carrier ZP235KCE TED 750, ZP91KCE TF5 7M7, ZR300KCE TEC 951, ZR300KCE TED 951, ZR90K3E TWD 961

Product Details

Factory Authorized Parts™ - ZP235KCE-TED-750 - Compressor Scroll

Please note, this is a special order, non-stock item and will be shipped direct from the vendor. Non-stock and Special Order items cannot be cancelled once processed, and are non-returnable. Customer is responsible for freight charges. These items may have an extended lead time, up to 4-6 weeks. By purchasing this product, you agree to these terms.

Attributes

Amps	23.6
Phase	Three
Voltage	380-420/460 VAC
Oil Type	Polyolester (POE)
UL Listed	Yes
BTU Output	235,000
Protection	External Enhanced
Cycle/Hertz	50/60 Hz
Refrigerant	R-410A
Displacement	13.25 (in^3/Rev)
Compressor Type	Scroll
Sound Level (dBA)	87
Compressor Housing	Hermetic
Liquid Temperature	85°F to 115°F (29.44°C to 46.11°C)
Mass Flow (lbs/hr)	3460 lbs./hr.; 3590 lbs./hr.
Mounting Dimensions	10.5” x 10.5” x 29”
Rated Load Amps (RLA)	30.4
Substantial Commodity	Steel
Condensing Temperature	100°F to 130°F (37.78°C to 54.44°C)
Return Gas Temperature	65°F (18.33°C)
Suction Line Size (OD)	1 ⅝”
Evaporating Temperature	45°F (7.22°C)
Locked Rotor Amps (LRA)	225
Oil Charge Initial (oz.)	158
Discharge Connection Type	Stub
Suction Line Fitting Type	Stub
Discharge Connection Size (OD)	1 ⅜”
