Veris H931
SKU: CS2542130MPN: H931Alternate Part #: VER-H931
Hawkeye 931 Split-Core 4-20mA Output Loop-Powered Current Transducers with Patented Integral Command Relay, Amp Range 0-30/60/120A
$109.86
Unit2 Units Available at Factory - Ships Same/Next Business Day
Product Details
Hawkeye 931 Split-Core 4-20mA Output Loop-Powered Current Transducers with Patented Integral Command Relay, Amp Range 0-30/60/120A
The Hawkeye 931 provide accurate load trending information with a proportional 4-20mA output signal. This combined with the integrated command relay makes these products ideal for start/stop and monitoring of motors. The relay is fully isolated from the current sensor and all relay connections are externally available for maximum flexibility.
Attributes
| Analogue Output Type | 4…20 mA |
| Product or Component Type | sensor |
| Ambient Air Temperature for Operation | -15-60 °C |
| Product Certifications | UL; CE |
| Type of Measurement | AC current |
| Device Application | building automation systems |
| Mounting Support | split core housing |
| Sensor Type | current transducer, AC |
| Relative Humidity | 10-90 % RH, non-condensing |
| Relay Type | mechanical |
| Network Frequency | 50…60 Hz |
| Switch Function | SPST |
| AWG Gauge | AWG 24…AWG 14 |
| Relay Coil Voltage | 24-24 V AC; 24-24 V DC |
| Current Measurement Range | 0…30 A; 0…60 A; 0…120 A |
| Current Measurement Accuracy | ± 2 % of full scale above 10 % of selected range |
| Opening Width | 21 mm |
| Load Type | inductive: 2 Aat250 V AC; inductive: 2 Aat30 V DC; resistive: 5 Aat250 V AC; resistive: 5 Aat30 V DC |
