Veris H720
SKU: CS1006746MPN: H720Alternate Part #: VER-H720
Current Transducer: 0 to 200A continuous, 4-20mA
$144.26
Unit3 Units Available at Factory - Ships Same/Next Business Day
Product Details
Current Transducer:
- 0 to 200A Continuous* 4-20mA Output
Attributes
| Analogue Output Type | 4…20 mA |
| Product or Component Type | sensor |
| Ambient Air Temperature for Operation | -15-60 °C |
| Product Certifications | UL |
| Type of Measurement | AC current; variable frequency drive (VFD) |
| Device Application | building automation systems |
| Mounting Support | solid core housing |
| Sensor Type | current transducer, VFD |
| Relative Humidity | 10-90 % RH, non-condensing |
| Network Frequency | 50…60 Hz |
| AWG Gauge | AWG 24…AWG 14 |
| Current Measurement Range | 0…200 A |
| Current Measurement Accuracy | ± 1 A |
| Opening Diameter | 18 mm |
Specifications
| SKU | CS1006746 |
|---|---|
| MPN | H720 |
| Alternate Part # | VER-H720 |
