Veris H922
SKU: CS666574MPN: H922Alternate Part #: VER-H922
Current Sensor: 0-5VDC Analog Output, 0-30/60/120A field selectable Amp Range, Split-Core Housing, UL Listed for use on 75 deg. C insulated conductors
$68.81
Unit3 in stock
Product Details
Current Sensor:
- 0-5VDC Analog Output* 0-30/60/120A field selectable Amp Range* Split-Core Housing* UL Listed for use on 75 deg. C insulated conductors
Attributes
| Analogue Output Type | 0…5 V DC |
| Product or Component Type | sensor |
| Ambient Air Temperature for Operation | -15-60 °C |
| Product Certifications | UL; CE |
| Type of Measurement | AC current |
| Device Application | building automation systems |
| Mounting Support | split core housing |
| Sensor Type | current transducer, AC |
| Relative Humidity | 10-90 % RH, non-condensing |
| Network Frequency | 50…60 Hz |
| AWG Gauge | AWG 24…AWG 14 |
| Current Measurement Range | 0…30 A; 0…60 A; 0…120 A |
| Current Measurement Accuracy | ± 2 % of full scale above 10 % of selected range |
| Opening Width | 21 mm |
Specifications
| SKU | CS666574 |
|---|---|
| MPN | H922 |
| Alternate Part # | VER-H922 |
