Veris H932
SKU: CS2542131MPN: H932Alternate Part #: VER-H932
Split Core 0-5VDC Output Self-Powered Current transducer w/Patented Integral Command Relay, coil 24VAC/DC@15mA, Contact Form A SPST
$92.07
UnitAvailable on backorder
Product Details
Split Core 0-5VDC Output Self-Powered Current transducer w/Patented Integral Command Relay, coil 24VAC/DC@15mA, Contact Form A SPST - The Hawkeye 932/952 provide accurate load trending information with a proportional 0-5VDC output signal. This combined with a separate intergral command relay make these products ideal for start/stop and status of HVAC motors.
Attributes
| Analogue Output Type | 0…5 V DC |
| Product or Component Type | sensor |
| Ambient Air Temperature for Operation | -15-60 °C |
| Product Certifications | UL; CE |
| Type of Measurement | AC current |
| Device Application | building automation systems |
| Mounting Support | split core housing |
| Sensor Type | current transducer, AC |
| Relative Humidity | 10-90 % RH, non-condensing |
| Relay Type | mechanical |
| Network Frequency | 50…60 Hz |
| Switch Function | SPST |
| AWG Gauge | AWG 24…AWG 14 |
| Relay Coil Voltage | 24-24 V AC; 24-24 V DC |
| Current Measurement Range | 0…30 A; 0…60 A; 0…120 A |
| Current Measurement Accuracy | ± 2 % of full scale above 10 % of selected range |
| Opening Width | 21 mm |
| Load Type | inductive: 2 Aat250 V AC; inductive: 2 Aat30 V DC; resistive: 5 Aat250 V AC; resistive: 5 Aat30 V DC |
Specifications
| SKU | CS2542131 |
|---|---|
| MPN | H932 |
| Alternate Part # | VER-H932 |
