Federal Signal LSB-024-240

Name: Federal Signal LSB-024-240
SKU: CS6290644
Price: 226.71 USD
Availability: OutOfStock

SKU: CS6290644MPN: LSB-024-240Alternate Part #: 148898

BASE ASSY, LITESTAK

$226.71

Unit

Available on backorder

Quantity

remove

add

Product Details

BASE ASSY, LITESTAK

Enclosure	Litestack - Surface mount or ¾” conduit mount
Configuration Modification	None

Input	Relay
Color(Base)	Black
Light Source	Incandescent
Base Material	Polycarbonate
Horn Decibels	Adjustable, up to 75-77 dBa @ 10’ (85-87 dBa @ 1m)
Product Weight	LSL Light Module: 0.8 lbs (0.4 kg) LBS Base: 1.0 lbs (0.4 kg) LSH Piezoelectric Horn: 0.65 lbs (0.3 kg)
Supply Current	LSL Light Modules: 0.76 amps \| LHS Piezoelectric Horn: 70mA Note*: Operating current listed is for one module. For multiple modules, the current will have to be added together throughout the configuration to get the total operating current.
Supply Voltage	24 VDC
Life Expectancy	Lamp: 2,500 Hours
Agency Approvals	UL Listed, CSA Certified
Enclosure Rating	NEMA 1 \| IP 10
Product Dimensions	LSB Base, LSL Module, and LSH Piezoelectric Horn (D x H): 3.93” (99.8mm) x 3.25” (82.6mm) LSBS Base (D x H): 3.93” (33.8mm) x 3.25” (82.6mm)
Light Module Colors	Amber, Blue, Clear, Green and Red
Operating Temperature Range	32-120°F (0-49°C)
