Eaton 12100RDS7250

Name: Eaton 12100RDS7250
Brand: Eaton
SKU: CS5018469
Price: 364.64 USD
Availability: OutOfStock

SKU: CS5018469MPN: 12100RDS7250UPC/EAN: 782114231401

Eaton Comet 18mm tubular photoelectric sensor

$364.64

Unit

Available on backorder

Quantity

remove

add

Product Details

Eaton Comet 18mm tubular photoelectric sensor,Through Beam, Right Angle, Output ON, 6.6 ft, 300 mA AC/DC at 20-264 Vac/15-30 Vdc, PVC, AC: L1 switched, DC: NPN open collector, 15-30 Vdc (NPN), 20-264 Vac 50/60 Hz

Attributes

Cable Type	Polyvinyl Chloride (PVC)
Contact Configuration	DC: NPN open collector AC: L1 switched
Contact Rating	300 mA AC/DC at 20-264 Vac/15-30 Vdc
Enclosure Material	Polyurethane foam (RIM)
Environmental Rating	NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 12, NEMA 13, IP69K
Input Voltage	20-264 Vac at 50/60 Hz, 15-30 Vdc (NPN)
Led Indicator	Output ON
Maximum Ac Current	300 mA
Maximum Dc Current	300 mA
Operating Temperature Max	158 FAH
Operating Temperature Max Uom	FAH
Operating Temperature Min	-4 FAH
Operating Temperature Min Uom	FAH
Protection	Auto reset short circuit
Sensor Type	Through beam
Series	Comet
Type	Photoelectric Sensor
