Eaton 14102A6513

Name: Eaton 14102A6513
Brand: Eaton
SKU: CS3142453
Price: 429.78 USD
Availability: OutOfStock

SKU: CS3142453MPN: 14102A6513UPC/EAN: 782113824543

Eaton Comet 18mm tubular photoelectric sensor

Eaton 11102A6517, 12102A6517, 13100R6517, 13104R6513, 13104RS5013, 14101A6517, 14101R6513, 14102A6513

Eaton 14102A6513, 14102AQD03, 14102AQD07

$429.78

Unit

Available on backorder

Quantity

remove

add

Product Details

Eaton Comet 18mm tubular photoelectric sensor, Retroreflective, Forward Viewing, Output ON, 6.6 ft, 300 mA AC/DC at 20-264 Vac/15-30 Vdc, PVC, AC: L1 switched, DC: NPN open collector, 20-264 Vac 50/60 Hz, 15-30 Vdc (NPN)

Attributes

Cable Type	Polyvinyl Chloride (PVC)
Contact Configuration	AC: L1 switched DC: NPN open collector
Contact Rating	300 mA AC/DC at 20-264 Vac/15-30 Vdc
Enclosure Material	Polyurethane foam (RIM)
Environmental Rating	NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 12, NEMA 13, IP69K
Input Voltage	20-264 Vac at 50/60 Hz, 15-30 Vdc (NPN)
Led Indicator	Output ON
Maximum Ac Current	300 mA
Maximum Dc Current	300 mA
Operating Temperature Max	158 FAH
Operating Temperature Max Uom	FAH
Operating Temperature Min	-40 FAH
Operating Temperature Min Uom	FAH
Protection	Latching short circuit
Sensor Type	Retroreflective
Type	Photoelectric Sensor
