Eaton 12100AQD03
SKU: CS5018465MPN: 12100AQD03UPC/EAN: 782113843445
Eaton Comet 18mm tubular photoelectric sensor
$464.15
UnitAvailable on backorder
Product Details
Eaton Comet 18mm tubular photoelectric sensor, Through Beam, 20 ft range, Forward Viewing, Output ON, Dual key micro, 300 mA AC/DC at 20-264 Vac/15-30 Vdc, 4 pin, AC: L1 switched, DC: NPN open collector, 20-264 Vac 50/60 Hz, 15-30 Vdc (NPN)
Attributes
| Connection | Dual key micro |
| Contact Configuration | DC: NPN open collector AC: L1 switched |
| Contact Rating | 300 mA AC/DC at 20-264 Vac/15-30 Vdc |
| Enclosure Material | Polyurethane foam (RIM) |
| Environmental Rating | NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 12, NEMA 13, IP69K |
| Input Voltage | 20-264 Vac at 50/60 Hz, 15-30 Vdc (NPN) |
| Led Indicator | Output ON |
| Maximum Ac Current | 300 mA |
| Maximum Dc Current | 300 mA |
| Number Of Pins | 4.0000 |
| Operating Temperature Max | 158 FAH |
| Operating Temperature Max Uom | FAH |
| Operating Temperature Min | -4 FAH |
| Operating Temperature Min Uom | FAH |
| Protection | Latching short circuit |
| Sensor Type | Through beam |
Specifications
| SKU | CS5018465 |
|---|---|
| MPN | 12100AQD03 |
| UPC/EAN | 782113843445 |
