Eaton 13106A6513

Name: Eaton 13106A6513
Brand: Eaton
SKU: CS3585684
Price: 429.78 USD
Availability: OutOfStock

SKU: CS3585684MPN: 13106A6513UPC/EAN: 782113823454

Eaton Comet 18mm tubular photoelectric sensor

$429.78

Unit

Available on backorder

Quantity

remove

add

Product Details

Eaton Comet 18mm tubular photoelectric sensor,Diffuse Reflective, Forward Viewing, Output ON, 6.6 ft, 300 mA AC/DC at 20-264 Vac/15-30 Vdc, PVC, AC: L1 switched, DC: NPN open collector, 20-264 Vac 50/60 Hz, 15-30 Vdc (NPN)

Attributes

Cable Type	Polyvinyl Chloride (PVC)
Contact Configuration	DC: NPN open collector AC: L1 switched
Contact Rating	300 mA AC/DC at 20-264 Vac/15-30 Vdc
Enclosure Material	Polyurethane foam (RIM)
Environmental Rating	NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 12, NEMA 13, IP69K
Input Voltage	20-264 Vac at 50/60 Hz, 15-30 Vdc (NPN)
Led Indicator	Output ON
Maximum Ac Current	300 mA
Maximum Dc Current	300 mA
Operating Temperature Max	158 FAH
Operating Temperature Max Uom	FAH
Operating Temperature Min	-40 FAH
Operating Temperature Min Uom	FAH
Protection	Latching short circuit
Sensor Type	Diffuse reflective
Series	Comet
Type	Photoelectric Sensor
