Square D ZB4BW533

Name: Square D ZB4BW533
Brand: Square D
SKU: CS4814217
Availability: OutOfStock

SKU: CS4814217MPN: ZB4BW533

Head for illuminated push button, Harmony XB4, metal, green flush, 22mm, universal LED, spring return, clear boot

Product Details

Green Flush Illuminated Pushbutton Head, Ø22 spring return for integral LED, Harmony XB4, Clear boot,

Ambient Air Temperature For Operation	-40-70 °C
Ambient Air Temperature For Operation 1	-40-70 °C
Ambient Air Temperature For Storage	-40-70 °C
Bezel Material	chromium plated metal
Device Presentation	basic sub-assemblies
Device Short Name	ZB4
Head Type	standard
Mechanical Durability	10000000 cycles
Mounting Diameter	22 mm
Operator Additional Information	clear boot
Product Certifications	UL listed# #CSA# #DNV# #LROS (Lloyds register of shipping)# #GL# #BV
Product Compatibility	integral LED
Product Or Component Type	head for illuminated push-button
Protective Treatment	TH
Range Of Product	Harmony XB4
Sale Per Indivisible Quantity	1.0000
Shape Of Signaling Unit Head	round
Standards	EN/IEC 60947-5-4# #EN/IEC 60947-1# #CSA C22.2 No 14# #JIS C8201-5-1# #UL 508# #EN/IEC 60947-5-1# #EN/IEC 60947-5-5# #JIS C8201-1
