Square D RE48AML12MW

Name: Square D RE48AML12MW
Brand: Square D
SKU: CS4812640
Price: 107.87 USD
Availability: OutOfStock

SKU: CS4812640MPN: RE48AML12MW

multifunction relay, Harmony Timer Relays, 5A, 2CO, 0.02s…300h, time delay, 24...240V AC DC

$107.87

Unit

Available on backorder

Quantity

remove

add

Product Details

Time Delay Relay 2 Functions - 0.02 s..300 h - 24..240

In Rated Current	0.208
In Rated Current 1	0.208
Ambient Air Temperature For Operation	-20-50 °C
Ambient Air Temperature For Operation 1	-20-50 °C
Ambient Air Temperature For Storage	-40-70 °C
Component Name	RE48A
Discrete Output Type	relay
Housing Material	self-extinguishing
Immunity To Microbreaks	10 ms
Marking	CE
Marking 1	CE
Maximum Switching Current	0.208
Mechanical Durability	30000000 cycles
Minimum Pulse Duration	20 ms
Minimum Switching Current	100 mA
Mounting Support	base mounted: socket# #panel mounted: system supplied with the product
On Load Factor	1.0000
Pick Up Duration	55 ms
Product Certifications	UL# #cULus# #CSA# #C-Tick
Product Front Plate Size	48 x 48 mm
Product Or Component Type	multifunction relay
Range Of Product	Harmony Timer Relays
Standards	IEC 61812-1# #EN 50081-½# #93/68/EEC# #89/336/EEC# #EN 50082-½# #IEC 60669-2-3# #73/23/EEC
Time Delay Range	0.5…30 s# #5…300 s# #0.2…12 min# #0.5…30 h# #2…120 s# #0.05…3 s# #0.2…12 s# #0.02…1.2 s# #2…120 min# #5…300 min# #0.5…30 min# #5…300 h# #2…120 h# #0.2…12 h
Time Delay Type	power on-delay# #interval# #off-delay# #symmetrical flashing
Time Delay Type 1	power on-delay# #interval# #off-delay# #symmetrical flashing
