Carrier ZP154KCE TFD 950

Name: Carrier ZP154KCE TFD 950
Brand: Carrier
SKU: CS4231017
Availability: OutOfStock

SKU: CS4231017MPN: ZP154KCE TFD 950Alternate Part #: CAR-ZP154KCE-TFD-950

Factory Authorized Parts™ - ZP154KCE-TFD-950 - Compressor

Carrier ZP103KCE TFD 855, ZP104KCE TFD 950, ZP120KCE TFD 855, ZP122KCE TFD 950, ZP154KCE TED 950, ZP154KCE TFD 950, ZP154KCE-TFD-855, ZP182KCE TED 950, ZR108KCE TF5 950, ZR108KCE TFD 950

Product Details

Factory Authorized Parts™ - ZP154KCE-TFD-950 - Compressor

Please note, this is a special order, non-stock item and will be shipped direct from the vendor. Non-stock and Special Order items cannot be cancelled once processed, and are non-returnable. Customer is responsible for freight charges. These items may have an extended lead time, up to 4-6 weeks. By purchasing this product, you agree to these terms.

Attributes

Amps	19
Phase	Three
Voltage	380-420/460 VAC
Oil Type	Polyolester (POE)
UL Listed	Yes
BTU Output	138,000
Protection	Internal Inherent Protection
Cycle/Hertz	60 Hz
Refrigerant	R-410A
Displacement	8.72 (in^3/Rev)
Compressor Type	Scroll
Sound Level (dBA)	80
Compressor Housing	Hermetic
Liquid Temperature	105°F to 115°F (40.56°C to 46.11°C)
Mass Flow (lbs/hr)	1930 lbs./hr.; 2290 lbs./hr.
Mounting Dimensions	7.5” x 7.5” x 23.03”
Rated Load Amps (RLA)	22.4
Substantial Commodity	Steel
Condensing Temperature	120°F to 130°F (48.89°C to 54.44°C)
Return Gas Temperature	65°F
Suction Line Size (OD)	1 ⅜”
Evaporating Temperature	45°F (7.22°C)
Locked Rotor Amps (LRA)	150
Oil Charge Initial (oz.)	110
Discharge Connection Type	Stub
Suction Line Fitting Type	Stub
Discharge Connection Size (OD)	⅞”
