Turck BIM-EG08-Y1X 7M
SKU: CS3789999MPN: BIM-EG08-Y1X 7MAlternate Part #: 1074008UPC/EAN: 4047101145731
1074008 - TRANS., BARREL, NAMUR, CABLE
$115.58
UnitAvailable on backorder
Product Details
Magnetic Field Sensor
Magnetic-inductive Proximity Sensor
- M8 × 1 threaded barrel
- Stainless steel, 1.4427 SO
- Rated operating distance 78 mm with DMR31-15-5 magnet
- DC 2-wire, nom. 8.2 VDC
- Output acc. to DIN EN 60947-5-6 (NAMUR)
- Cable connection
- ATEX category II 1 G, Ex zone 0
- ATEX category II 1 D, Ex zone 20
- SIL2 (Low Demand Mode) acc. to IEC 61508, PL c acc. to ISO 13849-1 with HFT0
- SIL3 (All Demand Mode) acc. to IEC 61508, PL e acc. to ISO 13849-1 with redundant configuration HFT1
Attributes
| Ambient Temperature | -25…+70 °C |
| Approvals | ATEX II 1 G, ATEX II 2 G, ATEX II 3 G, ATEX II 1 D, ATEX II 2 D, ATEX II 3 D, SIL2, PLc |
| Construction Size | M8 x 1 |
| Customs Tariff Number | 85365019900.0000 |
| Design | Threaded barrel |
| Ecl Ss Code V5 1 4 | 27270104 -/- Magnetic inductive proximity switch |
| Electrical Connection | Cable |
| Housing Material | Stainless steel, 1.4427 SO |
| Output Function | NAMUR |
| Protection Class | IP67 |
| Rated Switching Distance | 78 mm |
| Special Feature | Magnetic-inductive |
Specifications
| SKU | CS3789999 |
|---|---|
| MPN | BIM-EG08-Y1X 7M |
| Alternate Part # | 1074008 |
| UPC/EAN | 4047101145731 |
