Eaton 13100RS3310

SKU: CS5018796MPN: 13100RS3310UPC/EAN: 782113979373

Eaton Comet 18mm tubular photoelectric sensor

Eaton 11100AQD03, 11100AQD07, 11100RS2145, 11100RS7040, 11100RSW6513, 11102AF1213, 11104A6517, 12100AQD07, 12100RDS2145, 12100RF1217, 12100RSW6513, 12102AF1213, 12104A6517, 13100AS2200, 13100AS5055
Contact us for pricing and availability

Product Details

Eaton Comet 18mm tubular photoelectric sensor, Right Angle, Sensor dist 24 in., 300 mA max AC L1 switched/DC NPN open coll, 300 mA AC/DC at 20-264Vac/15-30Vdc, 6.6 Ft.(2m) Cable, 20-264 Vac/15-30 Vdc input, Diffuse Reflective, 6.6 Ft.(2m)

Attributes

Cable Type Polyvinyl Chloride (PVC)
Connection 6.6 ft (2 m) cable
Contact Configuration AC: L1 switched DC: NPN open collector
Contact Rating 300 mA AC/DC at 20-264Vac/15-30Vdc
Enclosure Material Lens: polycarbonate Cable jacket: PVC Body: structural polyurethane foam
Environmental Rating NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP68, IP69K
Input Voltage 20-264 Vac, 15-30 Vdc
Led Indicator Output status: red
Maximum Ac Current 300 mA
Maximum Dc Current 300 mA
Operating Mode Diffuse reflective
Operating Temperature Max 158 FAH
Operating Temperature Max Uom FAH
Operating Temperature Min -40 FAH
Operating Temperature Min Uom FAH
Protection Latching short circuit
Sensor Type Diffuse reflective
Switch Type Photoelectric

Specifications

SKUCS5018796
MPN13100RS3310
UPC/EAN782113979373
