Honeywell MS7403A2030

Zelix S03 Series Spring Return Direct Coupled Actuator, 24Vac/Dc, 3K Ohm 2-10Vdc

Product Features

• Zelix S03 Series Spring Return Direct Coupled Actuator
• 24 Vac/Dc
• 27 Lb-In Torque
• 3 Nm
• 3K Ohm 2-10Vdc (4-20 Ma with 500 Ohm Resistor) SPDT
• Floating Control Signal
• 2-10Vdc Feedback 7 VA
• Class 2
• NEMA 2
• 90 Second Nominal Driving Time
• 25 Second Maximum Spring Return
• Includes Mounting Bracket and Self Centering Shaft Adapter
• 5-95% RH Humidity Range
• 95±3 Degrees Rotational Stroke
• -40-149 Degree Ambient Temperature
