Honeywell M9164C1001

24V Non-Spring Return Foot Mounted Actuator w/ 2 internal aux. switches, 35 lb-in

Series 90 Modutrol IV motors non-spring return modulating proportional control motors used with controllers that provide a Series 90 output to operate dampers or valves.

Features

• Integral junction box provides NEMA 3 weather protection if motor is mounted in the upright position.
• Motor and circuitry operate from 24 Vac.
• Quick-connect terminals are standard--screw terminal adapter is available.
• Adapter bracket for matching shaft height of older motors is available.
• Motors have field adjustable stroke (90 to 160 degrees).
• Integral auxiliary switches are available factory mounted, or can be field added.
• All models have dual shafts (slotted and tapped on both ends).
• All models have auxiliary switch cams.
• Fixed torque throughout the entire voltage range.

Specifications

• Application Type: Electric
• Fail Safe Mode: Non-Spring Return
• Control Signal: Proportional, 135 ohm
• Feedback: no
• Motor Shaft: Dual ended Shaft
• Stroke: Adjustable; 90 to 160 degrees, Asymmetrical
• Torque Rating (lb-in.): 60 lb-in
• External Auxiliary Switches Available: Yes
• Frequency: 50 Hz, 60 Hz
• Power Consumption Driving (VA): 20 VA
• Electrical Connections: Quick Connect Terminals
• Shaft Dimensions (in.): .375 in
• Shaft Shape: Square
• Mounting: foot-mounted
• Dimensions: 6 7/16 in. high x 5 ½ in. wide x 8 ¾ in. deep
• Temperature Range: -40 to 150F
• Deadweight Load on Shaft (Either End) (lb): 200 lbs
• Deadweight Load on Shaft (Combined on both shafts) (lb): 300 lbs
• Nominal Timing (sec): 30 -60 sec
• Shaft Rotation (upon control signal increase): Clockwise (as viewed from power end) (normally closed)
• Auxiliary Switch Ratings AFL - 120 Vac: 7.2A
• Auxiliary Switch Ratings AFL - 240 Vac: 3.6A
• Auxiliary Switch Ratings ALR- 120 Vac: 43.2A
• Auxiliary Switch Ratings ALR- 240 Vac: 21.6A
